Microscan MS-3 User Manual page 200

Connectivity
Figure A-3 IC-331
SCANNER Pinouts
Pin
Host 232
No.
1 Power + 5 VDC
2
3
4 Power/Signal Ground
5
6
7 Output 1 TTL
8 Default Configuration
9 Trigger
10
11 Output 3 TTL
12 New Master (NPN)
13 Chassis Ground
14 Output 2 TTL
15
IB-131 Interface
The IB-131 interface simplifies connecting to the scanner by providing separate ports
for the host, power supply, trigger and network. The network port is used for multidrop
or daisy chain configurations. See the following pages for configuration diagrams and a
MS-3 Laser Scanner User's Manual
A-8
In/Out
Out
TXD In
RXD Out
NC
RTS In
In
Out
Out
CTS Out
In
Out
In
NC
Figure A-4 IC-331
EXTERNAL Pinouts (to IB-131)
Pin
Host 232
No.
1 Power + 10 to 28 VDC
2 TXD
3 RXD
4 Power/Signal Ground
5 Trigger (–)
6 RTS
7 Output 1 (+)
8 Default Configuration
9 Trigger (+)
10 CTS
11 Output 3 (+)
12 New Master (+)
13 Chassis Ground
14 Output 2 (+)
15 Output 1, 2, 3 (–)
In/Out
In
Out
In
In
Out
Out
In
In
In
In
Out
Out
