Output 2

Output 2

Serial Cmd: <K811,output on,polarity,pulse width,output mode>
Output 2 has the same parameters and default settings as Output 1.
Trend Analysis (output 2)
Definition: Applies trend analysis settings to Output 2.
Serial Cmd: <K781,trend analysis mode,number of triggers,number to output
on,decodes/trigger threshold>
Trend Analysis to Output 2 has the same parameters and default settings as Trend
Analysis to Output 1.
Diagnostic Warnings (output 2)
Definition: Applies warning to Output 2.
Serial Cmd: <K791,usused,service
rent low>
Diagnostic Warnings to Output 2 has the same parameters and default settings as
Diagnostic Warnings to Output 1.
MS-3 Laser Scanner User's Manual
6-24
threshold,unused,laser current high,laser cur-
