Test Button

Test Button Modes

Definition: Provides six user-selectable functions for each of the three test button
positions.
Serial Cmd: <K771,position 1 mode,position 2 mode,position 3 mode>
Defaults: As indicated
Options: As indicated
The positions are selected by the length of time the button is held. When you want to
select position one, you press and holds the button until one beep is emitted from the
scanner and the 20% LED is turned on. You then release the button to select position
one. If you want to select position two, you continue to hold until you hear two short
beeps and the 40% LED is turned on. Finally, to select position three, you continue to
hold the button until you hear three short beeps and the 60% LED is turned on.
For example, if you want to select the function for position three, you will hear one
short beep, then two short beeps, and finally three short beeps and the 20%, 40%, and
60% LEDs turn on in progression.
The following table lists the options for the three positions with the default position in
bold text:
Single Beep
0 = Disabled
1 = Read Rate
2 = Calibration
3 = Save for Power-on
4 = Auto Framing
5 = Load New Master
6 = Sleep Mode
Disabled: When set to Disabled, the button position will have no function associated
with it. The scanner will still respond when the button position is reached.
Read Rate: Read rate will perform decodes/second and is the same as sending a <C>
from the terminal. (See
the test button once quickly.
Calibration: The calibration routine will be initiated (see
page 1-9). To abort calibration, press the test button once quickly.
Save for Power-on: When when this button position is selected, all scanner settings
will be saved to non-volatile memory to be recalled when scanner is powered-on the
next time. This is the same as sending the <Z> in the terminal.
MS-3 Laser Scanner User's Manual
6-16
(table 6-1).
(table 6-1).
Table 6-1 Test Button Options
Two Beeps
0 = Disabled
1 = Read Rate
2 = Calibration
3 = Save for Power-on
4 = Auto Framing
5 = Load New Master
6 = Sleep Mode
"Read Rate" on page
Three Beeps
0 = Disabled
1 = Read Rate
2 = Calibration
3 = Save for Power-on
4 = Auto Framing
5 = Load New Master
6 = Sleep Mode
11-5.) To exit read rate mode, press
"Calibrate the Reader" on
