Trend Analysis (Output 1)
Usage: Useful in cases in which the user doesn't want to shut down for one con-
dition but wants to monitor quality and read conditions.
Definition: Applies trend analysis settings to Output 1.
With Trend Analysis, the user can track the occurrences and frequency
of mismatches, noreads, and the number of reads per trigger and output
the results to any of three outputs.
Example: Trend analysis mode = Noread
Number to Output On = 4
Number of Triggers = 5
In this example, the scanner will activate an output whenever 4 noreads
occur within 5 triggers (read cycles).

Trend Analysis Mode

Definition: Sets the trend condition (Mismatch, Noread, or Reads/Trigger) that
will activate the output.
Serial Cmd: <K780,trend analysis
on,decodes/trigger threshold>
Default: Noread
Options: 0 = Mismatch
1 = Noread
2 = Decodes per Trigger
Mismatch
Definition: Output will be activated when the number of Mismatches equals the
value entered for Number to Output On within the trigger window
selected in Trigger Evaluation Period.
Noread
Definition: The output will be activated when the number of noreads equals the
value entered for Number to Output On within the trigger window
selected in Trigger Evaluation Period.
