I/O Parameters - Microscan MS-3 User Manual

Chapter
6
Output Conditions by ESP Menu.................................................................6-2
I/O Parameters by Serial Command............................................................6-3
Symbol Data Output ....................................................................................6-4
Message Output ..........................................................................................6-7
Noread Message .........................................................................................6-8
Bad Symbol Message .................................................................................6-9
No Symbol Message .................................................................................6-10
Beeper .......................................................................................................6-11
Partial Output ............................................................................................6-12
Serial Verification ......................................................................................6-13
Test Button ................................................................................................6-15
Output 1.....................................................................................................6-18
Output 2.....................................................................................................6-24
Output 3.....................................................................................................6-25
Quality Output ...........................................................................................6-26
This section includes instructions for setting up conditions for beeper and test button
controls and for changing input/output of data messages and electrical transitions for
control of internal and external devices.
Note: The characters
not through ESP or serial commands.
Note: You can learn the current setting of any parameter by inserting a question mark
after the number, as in <K100?>. To see all "K" commands, send <K?>.

I/O Parameters

NULL <> and , can only be entered through embedded menus,
Chapter Contents
MS-3 Laser Scanner User's Manual
6-1
