Separator Status (UPC/EAN)
Note: UPC must be enabled for EAN to take effect.
Usage: Allows user to distinguish between the main and Supplemental sym-
bols.
Definition: Allows the user to insert a character between the standard UPC or EAN
symbol and the supplemental symbol when Supplementals is set to
Enabled or Required.
Serial Cmd: <K473,UPC status,EAN status,supplementals
tus,separator character,unused,UPC-E output as UPC-A>
Default: Disabled
Options: 0 = Disabled
Separator Character (UPC/EAN)
Note: If Separator Character has been changed to any other character and you wish
to re-define the separator as a comma, you will need to use ESP or the embedded
menu.
Usage: As required by the application.
Definition: Allows the user to change the separator character from a comma to a
new character.
Serial Cmd: <K473,UPC status,EAN status,supplementals status,separator sta-
tus,separator
Default: , (comma)
Options: Any ASCII character
Note: Whenever Separator Character is defined as a comma (,) sending a
<K473,s ?> command will return the current settings including the separator character
comma which appears after the separator status comma.

UPC-E Output to UPC-A (UPC/EAN)

Usage: Useful for applications that require UPC-A output.
Definition: Allows the user to change the output from UPC-E to UPC-A.
Serial Cmd: <K473,UPC status,EAN status,supplementals status,separator sta-
tus,separator
Default: , (comma)
Options: Any ASCII character
1 = Enabled
character,unused,UPC-E output as UPC-A>
character,unused,UPC-E output as
Chapter 5 Symbologies
status,separator sta-
UPC-A>
