Defaulting/Saving/Resetting
by sending a <D>
when enabled.
Caution: Be certain that you short the correct pins. Shorting the wrong pins can cause
serious damage to the unit.
Procedure:
Important: You must complete the default within one minute after power-on.
1. Locate and mark the default pins or wires connecting to default pins.
If using an IB-131 Interface, use pins 11 and 7 (figure A-2) on the HOST 25-pin
connector. Results will be more consistent if you attach a push button switch.
Pin 11
Figure A-2 Host Connector, 25-pin
(on side of IB-131 box)
2. Turn power to the scanner ON.
You should see the LED illuminators flash
cessful reset.
3. Momentarily short the default pins. Listen for a series of quick beeps, then short
the default pins again.
4. You should hear a longer beep. If not, repeat the process.
MS-3 Laser Scanner User's Manual
A-22
command from an auxiliary terminal via the auxiliary RS-232 port,
Pin 7
OFF and turn back ON, indicating a suc-
