Multisymbol

Usage: Commonly used in shipping applications where a shipping symbol con-
tains individual bar codes for part number, quantity, etc. This feature
allows one trigger to pick up all the symbols. AIAG and UCC/EAN-128 are
two application standards that address this need.
Definition: Allows the user to set up conditions that will allow more than one symbol
to be decoded and output.
Conditions The following conditions apply:
1. All noread messages are posted at the end of the data string.
2. If more than one symbol is within the scan beam at the same time,
3. If Matchcode Type is set to Sequential or if Trigger is set to
4. The maximum number of characters in any one bar code (other than
5. The maximum number of characters in a single scan line is
6. The maximum number of characters for all symbols is 392, includ-
symbol data may not be displayed in the order of appearance.
Continuous Read 1 Output, Number of Symbols will default to
1 (if set to any number greater than 1).
PDF417) is 64.
(Code 39).
ing preamble, separators, and LRC.
