Table A-4 Host 25-pin Connector
Pin Function
1 External ground
2 Transmit data (RS-232)
3 Receive data (RS-232)
4 RTS
5 CTS
6 Output 2 (+)
7 Signal ground
8 Output 1 (+)
9 Trigger (–)
10 Trigger (+)
11 Default configuration
13 Receive data RS-422 (+)
14 Transmit data RS-422 (–)
15 Output 3 (+)
16 Receive data RS-422 (–)
17 Output 1/2/3 (–)
19 Transmit data RS-422 (+)
25 New master/OMR (in)
Table A-5 Trigger 4-pin Connector
Pin Function
1 Power + 10 to 28 VDC (out)
b
2 Trigger (–) (in)
3 Power Ground
a
4 Trigger (+) (in)
a. For NPN type, connect pins 1 and 4.
b. For PNP type, connect pins 2 and 3.
Table A-6 Power 3-pin Connector
Pin Function
1 Power Ground
3 Power + 10 to 28 VDC (in)
Table A-7 Scanner 15-pin Connector
Pin
1
2
3
4
5
6
7
8
9
10 CTS/Aux Receive RS-232/RS-422 (+)
11 Output 3 (+)
12 New master/OMR (out)
13 External ground
14 Output 2 (+)
15 Output 1/2/3 (–)
Table A-8 Network 25-pin Connector
Pin
1
2
3
6
a
7
8
13
14
15
16
17
19
Chapter Appendices
Function
Power + 10 to 28 VDC (out)
Transmit RS-232/RS-422 (–)
Receive RS-232/RS-422 (–)
Power/Signal Ground
Trigger (–) (out)
RTS/Aux Transmit/RS-232/RS-422 (+)
Output 1 (+)
Default configuration
Trigger (+) (out)
Function
Ground
Aux Receive RS-232
Aux Transmit RS-232
Output 2 (+)
Signal ground
Output 3 (+)
Receive data/RS-422 (+)
Transmit data/RS-422 (–)
Output 3 (+)
Receive data/RS-422 (–)
Output 1/2/3 (–)
Transmit data (RS-422+)
