Terminal Window

Terminal Window

To use the terminal mode, click on the
You will see the following window:
Copy, paste,
and save
Clear
screen
Terminal
screen
Click on Macros arrow to Add Macro,
Remove Macro or Edit Macro
The terminal screen allows you to enter serial commands (in red) from the macro box,
by copying, or directly from your keyboard.
The terminal screen also displays bar code data or information from the reader (in
blue).
You can also right click in the terminal screen to bring up a handy option box.
MS-3 Laser Scanner User's Manual
10-2
Terminal
Click on Macro to Run

Figure 10-11 Terminal Window

button.
Type in text
here to find
in terminal
window
Macro
List on
this bar
