Counters

Counters

Counter commands can be a numeric value from 00000 to 65,535. After reaching the
maximum numeric limit of 65,535, the counter will automatically roll-over and start
counting again at 00000. To obtain the cumulative total of counts after the roll-over has
occurred, add 65,536 per each roll-over (the scanner does not keep track of the num-
ber of roll-overs) to the current count.
Note: All counter values will be lost if power is recycled to the scanner or the scanner
receives a reset or save command.
Counter by ESP
You can access Counters from the Utilities menu.
Right-click the appropriate counter option and select
Clear to set counter to zero. Or, right-click on
MS-3 Laser Scanner User's Manual
11-6
Request to display count or
Counters and select Request All.
