RS-232/422 Host Port
Host RS-232/422 Status
Used only in Point-to-Point protocol, and not with RTS/CTS.
Usage:
Only changed if necessary to match host setting.
Definition:
Enables RS422. When RS422 is enabled, RS232 is disabled.
Serial Cmd:
<K102,status>
Default:
Disabled
Options:
0 = Disabled
Whenever RS422 is disabled, RS232 is enabled in the background. However, when Mul-
tidrop is enabled, the functioning protocol is RS485 regardless of the displayed status
of RS422. Before enabling RS422, first double-check that Multidrop is not enabled.
MS-3 Laser Scanner User's Manual
3-10
1 = Enabled
