Output 1

Number of Triggers (Trend Analysis)
Definition: The number of triggers to examine for the trend analysis condition.
Serial Cmd: <K780,trend analysis
on,decodes/trigger threshold>
Default: 0
Options: 0 to 255
Number to Output On (Trend Analysis)
Definition: Sets the number of Trend Analysis events (mismatches, noreads or
reads/trigger as configured by Trend Analysis Mode) to occur within
the Number of Triggers before activating the associated output.
Usage: For example, if Number to Output On is set to 3 and Trend Analysis
Mode is set to Noread, then the output will not be activated until 3
noreads have occurred.
Serial Cmd: <K780,trend analysis mode,number of
on,decodes/trigger threshold>
Default: 0
Options: 0 to 255
Decodes per Trigger (Trend Analysis)
Note: This setting only applies when Trend Analysis Mode is set to Decodes per
Trigger.
Definition: Sets the threshold for decodes required per trigger (read cycle) that
must occur before an output can be activated.
Example: Trend analysis mode = Decodes per Trigger
Number to Output On = 4
Number of Triggers = 25
Decodes per Trigger Threshold = 10
In this example, the scanner will activate an output whenever the num-
ber of decodes falls below the decodes per trigger threshold (10) for 4
trigger (read cycle) events.
Serial Cmd: <K780,trend analysis mode,number of triggers,number to output
on,decodes/trigger
Default: 0
Options: 0 to 65535
MS-3 Laser Scanner User's Manual
6-22
