Pharmacode
Bar Width Status (Pharmacode)
Serial Cmd:
<K477,status,fixed bar count status,fixed bar count, min. no. of bars,
bar
Default:
Mixed
Options:
0 = Mixed
2 = Wide
Direction (Pharmacode)
Definition:
Specifies the direction that a bar can be read.
Serial Cmd:
<K477,status,fixed bar count status,fixed bar count,min. no. of bars,
bar widths,direction,fixed threshold value>
Default:
Forward
Options:
0 = Forward
Fixed Threshold Value (Pharmacode)
Definition:
Used when Bar Width Status field is set to Fixed Threshold Value.
Serial Cmd:
<K477,status,fixed bar count status,fixed bar count,min. no. of bars,
bar widths,direction,fixed threshold value>
Default:
400
Options:
1 to 65535
MS-3 Laser Scanner User's Manual
5-26
widths,direction,fixed threshold value>
1 = Narrow
3 = Fixed Threshold Value
1 = Reverse
