Output 1

Output Mode

Definition: Sets the condition in which the discrete output is de-activated.
Serial Cmd: <K810,output on,polarity,pulse
Default: Pulse
Options: 0 = Pulse
1 = Latch Mode 1
Pulse
Definition: This is the default mode of operation in which the programmable output
is activated when the Output On condition has been met and held active
for the duration of the selected pulse width.
Latch Mode 1 (Unlatch on New Master Change)
Definition: The programmable output will be activated when the Output On condi-
tion is met and will stay active until the state of the new master pin
changes from inactive to active or the configuration button is depressed
in the appropriate mode.
Important Note: To unlatch using the new master pin the new master pin
status must be set to disabled. To unlatch using the button the button
status must be set to unlatch mode.
Latch Mode 2 (Unlatch Opposite Condition)
Definition: The programmable output is activated when the Output On condition
has been met and held active until the opposite condition selected under
Output On has been met.
For example, if Noread is enabled under Output On, the programmable
output will go active upon a noread and remain active until the opposite
condition, a good read, occurs.
Latch Mode 3 (Unlatch Enter Read Cycle)
Definition: The programmable output is active when the Output On condition has
been met and is held active until a new read cycle begins.
NOTE: All of the Output On modes are inhibited when any Output on Warning is
active for Output 1 (see <K713> command).
MS-3 Laser Scanner User's Manual
6-20
width,output mode>
2 = Latch Mode 2
3 = Latch Mode 3
