Master Symbol Database

Master Symbol Database

See "Master Database" on page 11-8
Usage: Useful where more than one master symbol is required, as in a Multi-
symbol setup, for matching and other matchcode operations.
Definition: Allows you to define up to 10 master symbols as the master symbol data-
base, which can be entered by keyboard, scanned in, displayed, or
deleted by serial or ESP commands.
Request Master Symbol Data
Definition: Returns master symbol data for any enabled master symbols from 1 to
10.
For example, to request master symbol #5, enter <K231?,5>. The scan-
ner transmits the following format: <K231,5,data>. If no master symbol
data available, the output will be: <M5/?>.
Serial Cmd: Send
symbol for a specific master symbol.
Returns all master symbols if no number is added before the question
mark.
Options: 1 to 10
Request All Master Symbols Data
Definition: Returns master symbol data for all enabled master symbols from 1 to 10.
Serial Cmd: Send <K231?> to request all current master symbols.

Delete Master Symbol Data

Definition: Delete Master Symbol Data allows you to delete an enabled master
symbol.
Serial Cmd: Send
Options: 1 to 10
MS-3 Laser Scanner User's Manual
7-10
<K231?,master symbol
<K231,master symbol
for more detailed information.
number> to request the current master
number,> to delete the master symbol.
