Interleaved 2 of 5

Usage: It is has been popular because it is the most dense symbol for printing
numeric characters less than 10 characters in length; however we do not
recommend this symbology for any new applications because of inherent
problems such as truncation.
Definition: A dense, continuous, self-checking, numeric symbology. Characters are
paired together so that each character has five elements, two wide and
three narrow, representing numbers 0 through 9, with the bars repre-
senting the first character and the interleaved spaces representing the
second character. (A check digit is highly recommended.)
Important: You must set Symbol Length in order to decode I 2/5 sym-
bols.
Interleaved 2 of 5 Status
Serial Cmd: <K472,status,check digit
length #1,symbol length #2,unused,range mode>
Default: Disabled
Options: 0 = Disabled
status,check digit output
1 = Enabled
MS-3 Laser Scanner User's Manual
Chapter 5 Symbologies
status,symbol
5-13
