Pharmacode

Usage: Pharmacode is used mostly with packaging for the pharmaceuticals industry.
Definition: The symbol encodes up to five different numbers, each with its own color
which may be entered in decimal or "binary" format with a 1 represented
by a thick bar and a 0 represented by a thin bar. Bar width is independent
of height.
In decimal format, each part can be up to 999999.
In binary format, each input have up to 19 ones and zeros.
Note: It is recommended that you disable AGC before enabling Pharmacode.
Pharmacode Status
Serial Cmd: <K477,status, fixed bar count status,fixed bar count, min. no. of
bars,bar widths,direction,fixed threshold value>
Default: Disabled
Options: 0 = Disabled
Fixed Bar Count Status (Pharmacode)
Serial Cmd: <K477,status,fixed bar count
bars,bar widths,direction,fixed threshold value>
Default: Disabled
Options: 0 = Disabled
Fixed Bar Count (Pharmacode)
Serial Cmd: <K477,status,fixed bar count status,
bar widths,direction,fixed threshold value>
Default: 10
Options: 2 to 16
Minimum Bars (Pharmacode)
Serial Cmd: <K477,status,fixed bar count status, fixed bar count,
bar widths,direction,fixed threshold value>
Default: 4
Options: 2 to 16
1 = Enabled
status, fixed bar count, min. no. of
1 = Enabled
fixed bar
MS-3 Laser Scanner User's Manual
Chapter 5 Symbologies
count, min. no. of bars,
min. no. of bars,
5-25
