Trend Analysis
Tracks the occurrences and frequency of mismatches, noreads, and the number of
reads per trigger and output the results to any of three outputs.
Validation
(Not yet implemented)
Diagnostic Warning
The output remains active as long as one of the diagnostic conditions is met.
Polarity
Definition: Sets the polarity of the discrete output.
When set to Negative polarity, and an output condition from the scanner
is met, the output-1 pin on the scanner's 15 pin connector go low for the
time specified in Pulse Width. (See
tor, 15-pin Socket," on page
Serial Cmd: <K810,output on,polarity,pulse width,output mode>
Default: Negative
Options: 0 = Negative
Pulse Width
Definition: Sets the time in 1 mS increments that the discrete output remains active.
Serial Cmd: <K810,output
Default: 50 (50 mS)
Options: 0 to 65535 (0 to 65.535 seconds). Divide the number entered on the
command line by 1000 for time in seconds.
A-4.)
1 = Positive
on,polarity,pulse width,output mode>
MS-3 Laser Scanner User's Manual
Chapter 6 I/O Parameters
Table A-3, "MS-3 Laser Connec-
6-19
