Enter Master Symbol Data

Definition: Allows you to enter master symbol data for a specific master symbol
index number (1 to 10), provided the index number is not larger than the
number of symbols enabled by the Master Symbol Database Size (see
page
you will not be able to enter data for symbols 3 through 10.
ESP: 1. Double-click
index number you
want to setup and
copy or type in your
data in the popup data
entry box.
2. Click on the
Database to Reader
button.
Note: You can also click
Receive Reader's Data-
base
ner's current database
settings or click
from a symbol that is in the scanner's read range.
Serial Cmd: <K231,master symbol number,master symbol
Default: 1, blank
Options: 1 to 10, any combination of ASCII text up to the maximum indicated in
"Maximum Characters for Master Symbol Database" on page
For example, to enter data for master symbol 9, after making certain that
master symbol database size is enabled for 9 or more symbols (see
"Master Symbol Database Size" on page
<K231,9,data>.
Caution: Since the total number of characters available for the master symbol data-
base is 128, changes to the Master Symbol Database Size will re-allocate the num-
ber of characters available for each master symbol and could cause existing master
symbols to be deleted (except master symbol #1 unless it also exceeds the size limita-
tion).
Table 11-3, "Maximum Characters for Master Symbol Database," on page 11-
10 specifies the maximum number of characters available to each symbol according to
the number of master symbols defined, from 1 through 10. See
Database Size" on page 11-8.
11-8). For example, if Master Symbol Database Size is set to 2,
on each
Send
to enter the scan-
Read Symbol into Selected Index
Chapter 11 Utilities
data>
11-8), send
"Master Symbol
MS-3 Laser Scanner User's Manual
to enter the data
11-10.
