Mailbox block. Pager notification is enabled determines if notifications will be
made or not. Notify on urgent message only determines which type of new
messages will trigger a notification. Station is where the Station block is
specified. Dial is the actual pager phone number.
The default station block assigned is the Beepers block. Much like the Off
Premise block, the Beepers block is already configured to dial 9 to access an
outside line. But unlike the Off Premise block, the Beepers block has a suffix
string that is dialed.
The default setting for the suffix is ~diW,$K##. The "~di" tells the system to use
inband DTMF. This is because the default dialing is out of band, which most
pagers cannot interpret. The capital W tells the system to wait for an answer
from the pager. The comma says to wait one second after the answer. The "$K"
tells the system to dial the Mailbox number. The "##" ends the call.
Note that some pager companies answer with a nonstandard greeting or beep,
so the capital W may not correctly recognize the answer. In these cases it may
be necessary to replace the capital W with a series of pauses. A comma will
insert a one second pause and a backslash (\) will insert a 4 second pause. It
may be necessary to make several test calls to find the correct number of
pauses to insert. For this example we will assume that the standard suffix is
sufficient.
But the customer requires the page to include the number of new messages.
From the chart in section 8.1.6 of this manual we know that the sequence to dial
the number of new messages is "$N".
So in the default suffix we will need to add "$N", but we also need to include a
separator character so that the number of new messages is discernable from the
Mailbox number. We will use * for the separator. This means the suffix should
now be ~diW,$K*$N##.
Programming:
On the MWI & AutoForward screen of the subscriber's Mailbox block set Pager
notification is enabled to Yes.
Ensure Station set to Beepers.
Set Dial to the beeper phone number and click Save. Remember that a 9 is not
necessary.
On the General screen of the Station block named Beepers change the Suffix
field to ~diW,$K*$N## and click Save
Test the application by leaving a message in the subscriber's voicemail and
ensuring the pager is called.
