Velocity Control Mode - Panasonic MINAS A5-series Operating Instructions Manual

3
Connection
Outline
You can control the speed according to the analog speed command from the host con-
troller or the speed command set in the servo driver.
Host
controller
Function
(1) Velocity control by analog speed command
The analog speed command input voltage is converted to equivalent digital speed
command. You can set the filter to eliminate noise or adjust the offset.
• Relevant parameters
Parameter
No.
Pr3.00
Pr3.01
Pr3.02
Pr3.03
Pr4.22
Pr4.23
Note
For details of these parameters, refer to P.4-24, 25 and 37 "Details of parameter".
Related page
• P.3-14 "Control Block Diagram"
• P.3-18 "Wiring Diagram to the connector, X4"
3-6
1. Outline of mode
Velocity Control Mode
Analog
speed command Process of analog
speed command input
(±10V)
ZEROSPD input
AT-SPEED output
V-COIN output
Title Range
Speed setup, Internal/
External switching
Speed command
rotational direction
selection
Input gain of speed
10 to 2000
command
Reversal of speed
command input
Analog input 1 (AI1) −5578 to
offset setup
Analog input 1 (AI1)
0 to 6400
filter
Servo driver
Internal speed
command settings
Speed zero clamp (ZEROSPD) function
Attained speed output
Speed coincidence output
Unit
This driver is equipped with internal speed
0 to 3 — setup function so that you can control the
speed with contact inputs only.
Select the Positive/Negative direction
0 to 1 —
specifying method.
Based on the voltage applied to the
(r/min)
analog speed command (SPR), set up the
/V
conversion gain to motor command speed.
Specify the polarity of the voltage applied
0 to 1 —
to the analog speed command (SPR).
Set up the offset correction value applied
0.359mV
5578 to the voltage fed to the analog input 1.
Set up the time constant of 1st delay filter
0.01ms that determines the lag time behind the
voltage applied to the analog input 1.
Velocity
control
section
Function
