2. Pull the hard drive (3) out of the node by the latch handle (2).
Figure 118 Removing a node hard drive
.
To replace the component, pull out the latch handle (2) out as far as it can go and slide the drive into
the bay until the latch mechanism engages the chassis. Then, firmly push in the latch handle to lock
the drive in the drive bay.
Figure 119 Installing a node hard drive
.
NOTE:
The replacement drive is automatically configured to RAID 1 — no administrator action is required.

DVD-CD Drive

CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless all bays are
populated with either a component or a blank.
HP StorageWorks 281
