Cd-Rom Drive; Removing A Node Hard Drive - HP StorageWorks 6000 - Virtual Library System User Manual

3. Pull the hard drive out of the node by the latch handle (2).
Figure 98 Removing a node hard drive
.
NOTE:
Because the system disks in the node use software RAID to mirror the two drives, the node cannot
boot up from drive 1; a bootable drive must be installed in drive bay 0. To replace drive 0: remove
drive 0, remove drive 1, install previous drive 1 into drive bay 0, then install the new, blank drive
into drive bay 1.
To replace the component:
1. Pull out the latch handle out as far as it can go and slide the drive into the bay until the latch
mechanism engages the chassis. Then, firmly push in the latch handle to lock the drive in the
drive bay.
2. Power on the node. See
On reboot, the replacement drive is automatically configured to RAID 1 — no administrator
action is required.

CD-ROM Drive

1. Power off the node. See
NOTE:
The ejector button for the CD-ROM drive is recessed to prevent accidental ejection; it may
be helpful to use a small, blunt object, such as a pen, to push the ejector button.
2. Press the ejector button in firmly until the CD-ROM drive ejects (1).
268 Component Replacement
Powering on the VLS6000 series
Powering Off the System.
System.
