Online LED (green)
Off
Rear Panel Components
Item
Description
1
Power supply bay 0
2
Controller module
3
VHDCI connector
4
Fan module 0
5
Fan module 1
6
Power supply bay 1
WARNING!
Do not use the handles on the power supply units to lift or hold the disk array. These handles are
designed only for holding the power supply units or removing them from the disk array, not for
supporting the weight of the disk array.
Rear Panel LEDs and Buttons
Item
Description
1
Arrow buttons (not used)
254
Component Identification
Fault/ID LED (am-
Status
ber/blue)
Off
The drive is offline or the disk array is powered down.
