Power Supply Led Combinations - HP StorageWorks 6000 - Virtual Library System User Manual

Item Description
3 External health LED
4 Power On/Standby button
5 Hard drive activity LED
6 Hard drive online status LED
7 Hard drive fault status LED
8 9 Power supply LEDs
Table 12 Power supply LED combinations
8 Power LED 9 Fault LED (am-
(green) ber)
Off Off
244 Component Identification
Status
• Green = System health is normal.
• Amber = System is degraded. To identify the
component in a degraded state, refer to the
QuickFind Diagnostic Display LEDs.
• Red = System is critical. To identify the com-
ponent in a critical state, refer to QuickFind
Diagnostic Display LEDs.
• Off = System health is normal (when in
standby mode).
• Green = System is on.
• Amber = System is shut down (auxiliary
power only).
• Off = Power cord is not attached, power
supply failure has occurred, no power sup-
plies are installed, or facility power is not
available.
• On = Drive activity.
• Flashing = High activity on the drive or drive
is being configured as part of an array.
• Off = No drive activity.
For more information about the meaning of the
various hard drive LED illumination patterns, see
Hard drive LED
• On = Drive is part of an array and is cur-
rently working.
• Flashing = Online activity.
• Off = No online activity.
For more information about the meaning of the
various hard drive LED illumination patterns, see
Hard drive LED
• On = Drive failure.
• Flashing = Fault process activity.
• Off = No fault process activity.
For more information about the meaning of the
various hard drive LED illumination patterns, see
Hard drive LED
See Power supply LED
Status
No AC power
combinations.
combinations.
combinations.
combinations.
