Fan Locations
Item
Description
1
Fan module 1
2
Fan module 2
3
Fan module 3
VLS6600 Node Components, LEDs, and Buttons
Front Panel Components
Item
Description
1
DVD-CD drive
2
Video connector
3
USB connectors (2)
232
Component Identification
Fault/UID LED
Interpretation
(amber/blue)
Amber, flashing
A predictive failure alert has been received for this drive. Replace
regularly (1 Hz)
the drive as soon as possible.
Off
The drive is offline, a spare, or not configured as part of an array.
