3.
Connect the VHDCI connector on each disk array to the appropriate VHDCI connector on the
node using the SCSI cables provided
Figure 38 Connecting the VHDCI connector on each disk array to the appropriate VHDCI connector
on the node
.
Item
Description
1
VHDCI connector slot 8, A1, connect to Disk array 0
2
VHDCI connector slot 8, A2, connect to Disk array 1
3
VHDCI connector slot 8, B1, connect to Disk array 2
60
Hardware Installation
(Figure
38).
