CAUTION:
Changing the RAID configuration on your system will rebuild all of the storage pools and will delete
all data on the VLS. For this reason, it is important to establish the RAID configuration immediately.

Adding Capacity by Adding an Array

Add capacity by adding an array and a capacity license to the VLS. You can either purchase a
capacity bundle (which includes a new disk array and a capacity license), or you can add an existing
MSA20 disk array, the latest MSA20 firmware, and a purchased capacity license to the VLS.
NOTE:
To use an existing array, the array must have 12 blank drives of the same, supported type (for example,
all 12 are 750 GB disks).
To add a disk array:
1. Install the capacity license. See
CAUTION:
If a capacity bundle or disk array is added to the VLS before the capacity license is installed
for the disk array, a capacity license violation will occur. This will disable the VLS storage
capacity, so that the VLS is unable to perform for read/write operations. VLS storage capacity
is re-enabled once the capacity license is installed on the VLS (without needing to reboot).
2. Power off the node. See
3. Install the MSA20 disk array into the rack. See
4. Connect the VHDCI connector on the disk array to a VHDCI connector on the node. See
31 on page 56 or
5. Connect the AC input socket of each disk array power supply to an AC power source.
6. Power on the disk array. See
7. Power on the node. See
Virtual media will be automatically redistributed across the new storage when the tape is
overwritten.

Adding Capacity by Upgrading Disks in the Array

If the library has one or more array shelves with low capacity SATA disks (for example, 250 GB
disks), system capacity can be increased by upgrading these shelves to higher capacity disks (500
GB or 750 GB disks).
CAUTION:
This upgrade increases device capacity but erases all current virtual cartridges in the process.
Installing Additional
"Powering Off the
Figure 38 on page 60, depending on VLS model.
"Powering on VLS6000 Disk
"Powering on the VLS6000 series
Licenses.
System" on page 130.
"Installing the Disk Arrays into a
Arrays" on page 125.
System" on page 125.
Rack" on page 45.
Figure
