Fan Locations; Fibre Channel Switch 4/10Q Components, Leds, And Buttons; Front Panel Components - HP StorageWorks 9000 - Virtual Library System User Manual

Online/activity
LED (green)
Off
Off

Fan Locations

Item Description
1 Fan module 1
2 Fan module 2
3 Fan module 3

Fibre Channel Switch 4/10q Components, LEDs, and Buttons

Front Panel Components

Item Description
Fibre Channel port 0 through 9
1
(numbered from left to right)
2 Ethernet port
236 Component Identification
Fault/UID LED Interpretation
(amber/blue)
Amber, flashing A predictive failure alert has been received for this drive. Replace
regularly (1 Hz) the drive as soon as possible.
Off The drive is offline, a spare, or not configured as part of an array.
