LED Information

The Intel
troubleshooting your system. Table 10 lists these LEDs and provides a description of their
use.
LED Name
ID Aid in server
identification from the
back panel
System Fault Visible fault warning
Disk Activity Front panel
POST Code Display boot 80 POST
1-8 code
5-V Standby Identify 5-V standby
power on state
Power LED Identify the power state
of the system

BIOS POST Beep Codes

Table 11 lists the POST error beep codes. Prior to system video initialization, the BIOS
uses these beep codes to inform users of error conditions. Please note that not all error
conditions are supported by BIOS beep codes.
Number of
Beeps
3
112
®
Server System SR1630GP / SR1630HGP includes LEDs that can aid in

Table 10. LED Information

Function Location
Front panel
and board rear
left corner
Front panel
and board rear
left corner
Front panel
and board left
side
Left rear of
board
Front left
board
Front panel

Table 11. POST Error Beep Codes

System halted because a fatal error related to the memory was detected.
LED Color
Blue
Green or
Amber
Green
Each LED can
be Off, Green,
Amber, or Red
Amber
Green
Reason for Beeps and Action to Take
®
Intel Server System SR1630GP / SR1630HGP Service Guide
Notes
Press ID LED button or use
Server Management software
to turn the LED on and off.
•
On = No Fault
•
Green Blink = degraded
•
Amber = non-critical
Blinking = Activity. No action
required.
See the POST code table.
On = 5-V standby power on
•
Off = Power is off (off or
S5)
•
On = Power on or S0)
•
Slow Blink = Low power
state (S1 - S3)
