Intel ® Server System SR1600UR
Quick Start User's Guide
Thank you for buying an Intel Server System.
®
The following information will help you assemble
your Intel ® Server System SR1600UR (both hot-swap
and fixed drive systems) and install components.
This guide and other supporting documents
are located on the web at
http://www.intel.com/p/en_US/support/highlights/server/s5520ur.
If you are not familiar with ESD (Electrostatic Discharge) procedures
used during system integration, please see the Intel ® Server System
SR1600UR Service Guide, available on the Intel ® Server Deployment
Toolkit CD or at
http://www.intel.com/p/en_US/support/highlights/server/s5520ur.
Please boot to the Intel® Server Deployment Toolkit
CD first for BIOS and firmware configuration and updates.
Read all cautions and warnings first before starting your server system integration.
6
Warning
Install the Processor(s)
Read all caution and safety
statements in this document
Read all Cautions before proceeding.
before performing any of the
® When opening a socket, DO NOT
instructions. Also see the Intel
TOUCH the gold socket wires.
Server Board and Server Chassis
Safety Information document at:
When unpacking a processor, hold
http://www.intel.com/support/
by the edges only to avoid touching
motherboards/server/sb/cs-010770 the gold contact wires.
.htm for complete safety information.
NOTE: If you are only using one processor
on your server board, install the processor
on the CPU socket labeled 'CPU 1' on the
Warning
server board.
Installation and service of
this product should only be
performed by qualified service
personnel to avoid risk of injury from
electrical shock or energy hazard.
Caution
Observe normal ESD
8
[Electrostatic Discharge]
procedures during system
Install Memory DIMMs
integration to avoid possible
damage to server board and/or
Memory Configurations and Population Order:
other components.
For best performance, a minimum of three DIMMs per
Tools Required
CPU is recommended. In a single-processor
configuration, always populate A1 DIMM first. In a
dual-processor configuration, always populate A1
DIMM first for CPU 1 and D1 DIMM first for CPU2.
Note: For additional memory configurations, see the Service Guide
on the Intel Server Deployment Toolkit CD that accompanied
®
Phillips* Anti-static
your Intel Server System SR1600UR, or go to:
®
screwdriver
wrist strap
http://www.intel.com/p/en_US/support/highlights/server/s5520ur.
Intel is a registered trademark of Intel Corporation or its
subsidiaries in the United States and other countries.
* Other names and brands may be claimed as the property
of others. Copyright © 2011, Intel Corporation.
Memory sizing and configuration is supported only for qualified
All rights reserved.
DIMMs approved by Intel. For a list of supported memory, use the
Server Configurator Tool available at:
E52175-006
http://serverconfigurator.intel.com/default.aspx.
*E52175-006*
Hot-Swap Drive System
Fixed Drive System
B. Open the Load Plate
C. Remove the Socket
A. Open the Socket A
Push the rear tab with your
Lever finger tip to bring the front Protective Cover
end of the load plate
A
A up slightly. A Grasp the socket protective cover
Push the lever handle
by the two tabs and carefully lift
down and away from
straight up.
the socket to
release it.
To avoid damage, DO NOT
B Rotate the lever open
DROP the cover onto the
all the way.
socket wires or components.
A
Save the protective cover
B B
Open the load plate
for future use.
as shown.
B
To Install DIMMs:
CAUTION: Avoid touching contacts
DIMM B2
when handling or installing DIMMs.
DIMM B1
DIMM A1
DIMM A2 DIMM C2
DIMM C1
A
Open both DIMM socket levers.
B
Note location of alignment notch.
DIMM E1
C
Insert DIMM making sure the connector edge
DIMM F2 DIMM E2
DIMM D1 of the DIMM aligns correctly with the slot.
DIMM F1
DIMM D2
D
Push down firmly on the DIMM until it
snaps into place and both levers close.
E
IMPORTANT! Visually check that each
latch is fully closed and correctly
engaged with each DIMM edge slot.
E
Chan A Chan C
Chan B
Chan F Chan D
Chan E
A
Minimum Hardware Requirements
To avoid integration difficulties and
possible board damage, your system must
meet the following minimum requirements:
• Processor: Intel Xeon processor
® ®
5500 series with 2 MB cache support.
• Memory Type: Minimum of one
512-MB, 240-pin DDR3
800/1066/1333-MT/s DIMMs.
• Hard Disk Drives:
SATA/SAS
• Rack Mount Kit
(EIA 310-D compliant)
For a complete list of compatible
processors and memory, see
http://www.intel.com/p/en_US/
support/highlights/server/s5520ur
4
Remove Air Baffle and
Processor Air Duct
A
Remove the
air baffle.
B
Remove the
processor
air duct.
B
A
E. Install the Processor
D. Remove the
Processor
A
Orient the processor with the
CAUTION:
Protective Cover socket such that the orientation
The underside of the
notches on the processor align
processor has components
with the two orientation posts
A
Take the processor
that may damage the socket
on the socket.
out of the box and
wires if installed improperly.
Install the processor as shown.
remove the
Processor must align
protective shipping
Orientation Notch
correctly with the socket
cover.
opening before installation.
DO NOT DROP processor
into the
A
socket!
A
Components
9
Install I/O Expansion Module (optional)
A
Squeeze the sides of the filler panel(s) to disengage it from the server system back panel
and remove it. Note: If you are installing an I/O expansion module that uses only one slot,
remove the filler panel only from the slot shown so that the module can be attached to I/O
Connector 1; do not remove the filler panel from the other slot.
B
Install the standoffs to the server
board by pressing into the
holes as shown.
Note: For the 1-socket
module, install three
Fourth
standoffs as shown in
Standoff
gray. For the 2-socket Position
module, also install
the fourth standoff as
D shown in red.
I/O Connector 2
C
Position the module over
the server board, fit the
front of the module into the
C
back panel slot(s), and Snap
Standoff
B then attach the module to
the server board connector
Standoff
and engage the standoffs.
Hole
1 2
Preparing Remove the
the Top Cover
Chassis
A
Observe normal ESD Remove the security screw.
(Electrostatic Discharge)
B
Depress the latch.
procedures.
C
Slide cover back
and lift upward.
Place your
C
Intel ® Server
Chassis on a flat anti-static
surface to perform the
B
following integration A
procedures. Observe ESD
procedures before
reaching inside to make
server board connections
or install components.
5
Remove the Heatsink(s)
IMPORTANT!
CAUTION: The heatsink has thermal interface
material (TIM) on the underside of it. Use caution so
that you do not damage the thermal interface material.
Use gloves to avoid sharp edges.
Before proceeding
further, check your Intel ®
The heatsink is attached to the server board /
Server System for
processor socket with captive fasteners.
disconnected or loose
cables and components
Using a #2 Phillips* screwdriver, loosen the four
that may have occurred
screws located on the heatsink corners in a
during
diagonal manner using the following procedure:
shipping.
A
Using a #2 Phillips* screwdriver, start with
screw 1 and loosen it by giving it two rotations
and stop. (IMPORTANT: Do not fully loosen.)
B
Proceed to screw 2 and loosen it by giving it two
rotations and stop. Similarly, loosen screws 3
and 4.
C
Repeat steps A and B by giving each screw
two rotations each time until all screws are
loosened.
D
Lift the heatsink straight up.
7
Install the Heatsink(s)
F. Close Load Plate and
Socket Lever
IMPORTANT NOTE:
This Intel® Server Chassis requires passive heatsinks.
A
Close the load
plate all the
CAUTION: The heatsink has thermal interface
way as
material (TIM) on the underside of it. Use caution so
A
shown. that you do not damage the thermal interface material.
Use gloves to avoid sharp edges.
A
Remove the protective film on the TIM if present.
B
Align heatsink fins to the front and back of the chassis
for correct airflow. Airflow goes from front-to-back
of chassis.
B
Close the socket lever and
Each heatsink has four captive fasteners and should be tightened in a
ensure that the load plate tab
diagonal manner using the following procedure:
engages under the socket
C
lever when fully closed. Using a #2 Phillips* screwdriver, start with screw 1 and engage screw
threads by giving it two rotations and stop. (Do not fully tighten.)
D
Proceed to screw 2 and engage screw threads by giving it two
B
rotations and stop. Similarly, engage screws 3 and 4.
E
Repeat steps C and D by giving each screw two rotations each time
until each screw is lightly tightened up to a maximum of
8 inch-lbs torque.
Orientation Post Note: Heatsink styles may vary.
10
Install Intel® Remote Management Module 3 (optional)
A
Squeeze the sides of the RMM3 filler panel to disengage it from the server system back panel and remove it.
B Attach the RMM3 module bracket to the RMM3 module with two screws as shown.
C
Connect one end of the cable (labeled 'RMM3') to the RMM3 connector on the RMM3 module. Note that cable
connectors are keyed and can only go in one way.
D
Connect the opposite end of the cable (labeled 'server board') to the RMM3 connector on the server board.
E
Attach the module bracket to the
chassis with two screws as shown.
Note that screws install from the
back of the chassis.
A
C
B
B
I/O Connector 1 Filler Panels
3
Remove Add-in
Card Riser Assembly
To remove the riser:
Grasp the riser assembly with both
hands and lift straight up.
CAUTION:
Place the riser
assembly
upside down to
avoid damage
Riser Card
to the riser card
Connector
connector.
Remove the
Spacer
D
A
IMPORTANT: This spacer must be
removed and discarded before
opening the socket to install the
processor in Step 6.
TIM
CAUTION:
Do not
over-tighten
fasteners.
3
2
1
4
TIM
E
E
A
A
C
D
D
