If using a RAID configuration with SATA drives, make sure the RAID card is
installed correctly.

Bootable CD-ROM Disk Is Not Detected

Check the following:
•
Make sure the BIOS is configured to allow the CD-ROM to be the first bootable
device.

LED Information

The Intel
can aid in troubleshooting your system. A table of these LEDs with a description of their
use is listed below.
LED Name
Power Indicates system power
is on or off
HD Activity Visible indication of hard
drive activity
System Visible fault warning
Status
NIC1 Activity Visible indication of LAN
#1 activity
NIC2 Activity Visible indication of LAN
#2 activity
114
®
Server System SR1530CL / SR1530HCL / SR1530HCLS includes LEDs that

Table 7. LED Information

Function Location
Front control
panel
Front control
panel
Front control
panel and
back panel
Front control
panel
Front control
panel
LED Color
Green Off = Power is off or in sleep
state S4
Blink = Sleep S1
On = Power is on
Green Blink = Hard drive access
Green or Green = no fault
Amber
Green blinking = degraded
condition
Amber blinking = non-critical
error
Amber = critical or non-
recoverable error
See Table 8.
Green On = LAN link, no access
Blink = LAN access
Off = Idle
Green On = LAN link, no access
Blink = LAN access
Off = Idle
Server System User Guide
