LED Information

The Intel
that can aid in troubleshooting your system. Table 8 lists these LEDs and provides a
description of their use.
LED Name
Power Indicates system power
is on or off

BIOS POST Beep Codes

Table 9 lists the POST error beep codes. Prior to system video initialization, the BIOS
uses these beep codes to inform users of error conditions. Please note that not all error
conditions are supported by BIOS beep codes.
Number of
Beeps
1, 2, or 3
4 - 7 or 9 - 11
8
102
®
Server System SR1530AH / SR1530AHLX / SR1530HAHLX includes LEDs
Table 8. LED Information
Function Location
Front front
panel
Table 9. POST Error Beep Codes
Memory error. Reseat the memory or replace the DIMMs with known good
modules.
Fatal error indicating a possible serious system problem. Remove all add-
in cards and re-start the system. If the error still occurs, contact your
system manufacturer. If the beep codes are not generated after the add-in
cards are removed, insert the cards one at a time, booting the system
between each card addition, until the beeps again occur to reveal the
malfunctioning card.
Replace or reseat the system video add-in card. If on-board video is being
used, the server board may be faulty.
LED Color
Green
Reason for Beeps and Action to Take
®
Intel Server System SR1530SH/SR1530HSH User's Guide
Notes
Off = Power is off or in sleep
state S5
On = Power is on or in sleep
state S0
