- Page 1 Server System SR2625URLX ® Spares/Accessories List and Configuration Guide A reference guide to assist customers in ordering the necessary components to configure the Intel® Server Board S5520UR and the appropriate 1U and 2U Intel Rack Mount Server Systems November 1.6 November 2009...
-
Page 2: Revision History
FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to specifications and product descriptions at any time, without notice. -
Page 3: Table Of Contents
..........................19 ISER PARES AND CCESSORIES ..........................20 AILS AND OUNTING PTIONS ........................20 HASSIS AND LECTRICAL PARES INTEL® SYSTEM MANAGEMENT SOFTWARE ....................... 23 – O ........................23 RODUCT ESCRIPTIONS VERVIEW ® S – (U )................23 NTEL YSTEM ANAGEMENT... -
Page 4: System Product Order Codes
System Product Order Codes Product Descriptions – Overview Product based on the Intel® Server Board S5520UR will be offered in two methods at production: 1. Intel® Server Systems (Integrated SKUs). Customer orders an integrated system. All systems – except SR1600URHS – are complete and ready to use with installation of CPUs and memory. - Page 5 Same as SR1600UR but with North American power cord. SR1600URNA 901125 Intel Server System SR1600URHS Hot-Swap configuration. SR1600URHS Includes: 900985 • Intel Server Board S5520UR 735858206730 • Intel Server Chassis SR1600 • Standard control panel • 3 3.5" HDD carriers •...
- Page 6 For complete list of accessories – please reference section 2 Same as above but with North American power cord SR1625URNA 901132 Intel Server System SR1625UR active configuration. SR1625URSAS Includes: 900987 • Intel Server Board S5520UR 735858206754 •...
- Page 7 For complete list of accessories – please reference section 2. Same as above but with North American power cord SR1625URSASNA 901136 Intel Server System SR2600UR system in base-passive SR2600URBRP configuration. Includes: 901093 • Intel Server Board S5520UR 735858206761 •...
- Page 8 Same as above but with North American power cord SR2600URBRPNA 901187 Intel Server System SR2600UR in active-SAS configuration. SR2600URLX Includes: 900988 • Intel Server Board S5520UR 735858206778 • Intel Server Chassis SR2600 • Standard control panel • 5 3.5" HDD carriers •...
- Page 9 For complete list of accessories – please reference section 2. Same as above but with North American power cord SR2600URSATANA 903802 Intel Server System SR2625UR in base-passive SR2625URBRP configuration. Includes: 900989 •...
- Page 10 To add support for SATA Tape Drive – order ASR2500SATAPE For complete list of accessories – please reference section 2. Same as above but with North American power cord SR2625URBRPNA 901141 Intel Server System SR2625UR system in SAS SR2625URLX configuration. Includes: 900990 •...
-
Page 11: Spares And Accessories Order Codes
Intel 82598 EB controller. 900962 Compatible with S5520UR and S5500WB boards 735858206525 only. AXX4GBIOMOD2 Quad port GbE I/O module, based on Intel 82576 901359 controller. RJ-45 connectors. Compatible with 735858206532 S5520UR and S5500WB boards only. Single port QDR speed InfiniBand I/O Module. -
Page 12: Sr2600 And/Or Sr2625 Flex Bay Kits
Compatible with Intel Server Boards S5520UR, 735858185219 S5000PALR and S5400SF. Dual Port Gigabit Ethernet I/O Expansion AXXGBIOMOD Module. Based on Intel 82571EB GbE controller. 880518 Compatible with Intel Server Boards S5520UR, 735858184779 S5500WB, S5000PALR and S5400SF. SR2600 and/or SR2625 Flex Bay Kits... -
Page 13: Bezels
00735858183895 * ADRBEZBLACK shown. ADWLCDBEZEL SR1600/1400/1500 Black Bezel with cutout for 882435 Intel Local Control Panel (LCD). Note: requires Intel Local Control Panel. 00735858164993 ADRLCDBEZEL SR2600/2625/2500/2400 Black Bezel with cutout 857586 for Intel Local Control Panel (LCD). Note: requires Intel Local Control Panel. - Page 14 Intel® RAID Activation Key for AXXRAKSAS2 FALSASMP2 891290 Note: enabling RAID capability also 735858194730 requires mini DIMM (AXXMINIDIMM512) (Reused from SR1500/SR2500 system) AXXRAKSW5 Intel® RAID Activation Key 878958 AXXRAKSW5 enables SATA Host- 00735858181860 based RAID 5 AXXMINIDIMM512 512 MB Mini DIMM registered DDR-2...
- Page 15 AXXSATADVDRWROM 898051 (pending update to Slim SATA DVD+/-RW ROM Accessory 898292) 735858197670 AXXUSBFLOPPY SR1600/2600 USB Floppy Device 881267 Accessory (not compatible with 735858183260 SR1625/2625)) FPWRCABLENA 879287 North American Power Cord Spare 735858181129 SR1600/SR1500 (1U) Hotswap Passive SAS/SATA Backplane Kit . Compatible with either SAS or SATA 3.5”...
- Page 16 735858184243 cable. FURBRIDGE 901088 Bridge Board Spare 735858206709 SR1625/2600/2625UR SAS Midplane-2 with optional Intel® Integrated Server RAID (support RAID 6). FALSASMP2 8 port SAS controller with optional HW 892611 RAID upgrade. Note RAID requires new 735858198110 RAID activation key (MM# 891290) and new RAID mini DIMM (cache) each sold separately (MM# 897046).
-
Page 17: Power Sub-System Spares And Accessories
The 2.5” HDD carrier is for installing 2.5” AXX25DRVADPTR SAS, SATA, or SSD into 3.5” hot-swap 904083 hard disk drive bay. 00735858211567 See compatible Intel® chassis and systems at: http://www.intel.com//support/motherboards/ server/sb/CS-030726.htm BXSTS100P Spare passive thermal solution for 1U, 900492 2U rack servers and compute modules. -
Page 18: Control Panel Spares And Accessories
AXX750WPS SR2600/2625UR 750W Hot-Swap Power Supply 901681 Module 735858206501 FSR1600PS SR1600UR 600W fixed power supply spare 901086 module 735858206617 Control Panel Spares and Accessories Product Code Minimum Image Description Order Quantity ASR1625LCP 901013 SR1625 LCP Accessory Kit 735858206426 ASR2600LCP 901014 SR2600 LCP Accessory Kit 735858206457 AXLCPRACK2... -
Page 19: Riser Spares And Accessories
ASR1625FP 900991 SR1625UR Standard front panel accessory kit 735858206419 Riser Spares and Accessories Product Code Minimum Image Description Order Quantity SR2600/2625 5 slot PCI-e active Riser. Bridges are placed on riser to multiply provided 24 PCI Express 2.0 lanes into 40 for on-the-fly load ASR26XXFHLPR balance. -
Page 20: Rails And Mounting Options
Rails and Mounting Options Product Code Minimum Image Description Order Quantity Full extending Rail Kit, also compatible AXXHERAIL2 with SR1500/2500 chassis (new and 901082 improved design replacing AXXHERAIL. 735858206549 Existing AXXHERAIL may still be used with 16xx/26xx chassis) AXXRACKARM2 Cable Management Arm (Must be used 901084 with AXXHERAIL2, not compatible with 735858206563... - Page 21 Quantity FSRTCHSPR Combined chassis mechanical spare kit for 901994 SR16xx and SR26xx systems. Includes: • 735858208086 Baffle for power supply-backplane area for SR2600 • Baffle for power supply-backplane area for SR2625 • 1U and 2U CPU Ducts • PS Blank Filler •...
- Page 22 • Docking front panel board (for SR2600) • Cabled front panel board (for SR2625) • Optical drive interposer • Front panel cable • Front panel USB cable • Two 115mm+130mm redundant fan bracket cable assembly • One 140mm+140mm redundant fan bracket cable assembly •...
-
Page 23: Intel® System Management Software
Intel® System Management Software Product Descriptions – Overview Intel System Management Software provides upgrades SKUs. Customers may order an upgrade that will give them the ability to manage additional servers and clients. Intel® System Management Software – (Upgrade SKUs) The following Intel® System Management Software Upgrade SKUs are offered. Each SKU... - Page 24 SMS2SSE2STD 7 35858 19672 7 893170 Upgrade from 90 day trial Edition to Standard Edition Not included: Software CDs are not included with upgrade. SMS2CAL1S 7 35858 19675 8 893217 Microsoft® System Center Essentials 2007 Server Management License (1 Pack) Not included: Software CDs are not included with upgrade.
-
Page 25: Vmware Vsphere* Virtualization Software Configuration Guide For Vsphere* Skus
VMware vSphere* software is now available when ordering an Intel® Server Board or Intel® Server System. Customers can only order these SKUs at the time they are ordering an Intel® Server Board or Intel® Server System. These SKUs cannot be ordered individually. The number of VMware vSphere SKU purchase has to coincide with number of system or boards purchased. - Page 26 Product Description Code VMW4ESS 7 35858 21272 4 904791 Software license activation code certificate for VMware vSphere* 4 Essentials Bundle for 3 hosts (Max 2 CPUs per host and 6 cores per CPU) with 1 year VMware Subscription. VMW4ESSPLUS 904792 7 35858 21273 1 Software license activation code certificate for VMware vSphere* 4 Essentials Plus...
