3
Hardware Installations and
Upgrades
Caution: No components in the Intel
removing or installing any component in this server system, you must first take the server
out of service, turn off all peripheral devices connected to the system, turn off the system
by pressing the power button, and unplug the AC power cord from the system or wall
outlet.
Note: Some components in the Intel
noted as such (where applicable) in the following instructions.
Note: Most of the illustrations in this chapter show the Intel
optional optical drive installed. Unless otherwise noted, the instructions for removing and
installing components are the same for the Intel
instructions differ, separate illustrations are shown for the Intel
SR1630HGP.

Before You Begin

Before working with your server product, pay close attention to the
on page

Tools and Supplies Needed

•
Phillips* (cross head) screwdriver, #1 bit and #2 bit
•
Antistatic wrist strap and conductive foam pad (recommended)

System References

All references to the left, right, front, top, and bottom assume the reader is facing the front
of the server system as it would be positioned for normal operation.
®
Intel Server System SR1630GP / SR1630HGP Service Guide
®
Server System SR1630GP are hot-swappable. Before
®
iii.
Server System SR1630HGP are hot-swappable and are
®
®
Server System SR1630HGP. When
Server System SR1630GP with an
®
Server System
"Safety Information"
27
