Troubleshooting

LED Information

®
The Intel Server Board SE7210TP1-E includes LEDs that can aid in troubleshooting your system.
A table of these LEDs with a description of their use is listed below.
LED Name Function
ID Aid in server
identification from the
back panel
System fault Visible fault warning
IDE activity Front panel
Memory fault Identify failing memory
1–6 module
POST code 1–4 Display boot 80 POST
(LSB, bit1, bit2, code
MSB)
Fan Pack Fault Warn on fan failure
CPU 1 & 2 Fan Identify fan failure
Fault
CPU 1 & 2 Identify processor failure
Fault
5v Standby Identify 5v standby
power on state
Power LED Identify the power state
of the system
72
Location Color
Front Panel and Blue
board rear left
corner
Front panel and Green or Amber
board rear left
corner
Front panel and Green
board left side
DIMM end front of Amber
board
Left rear of board Each LED can be
Off, Green,
Amber, Red
Front center board Amber
Front center board Amber
1" behind processor Amber
socket
Front left board Amber
Front Panel Green
®
Intel Entry Server Platform SR1325TP1-E User Guide
Correction
Press ID LED button or user
Server Management
software to turn off the LED.
On
= No Fault
Green Blink = degraded
Amber = critical error or
non-recoverable
blink = non-
Amber
critical
Blinking = Activity. No action
required.
On = Fault
See the POST code table
On = Fault
On = Fault
On = Fault
On = 5v standby power on
Off
= Power is off (off
or S5)
On = Power on or S0)
Blink = Low
Slow
power state (S1 – S3)
