Installing the Processor

To install a processor, follow these instructions:
1. Observe the safety and ESD precautions at the beginning of this book. See
Information" on page
2. Power down the server and unplug all peripheral devices and the AC power cable.
3. Remove the server system cover. For instructions, see
System Cover" on page
4. Locate the processor socket and raise the socket handle completely. See
5. Push the rear tab with your finger to slightly lift the front of the load plate. Raise the
load plate completely. Raise the CPU load plate (see
40
iii.
30.

Figure 25. Lifting the Processor Socket Handle

®
Intel Server System SR1630GP / SR1630HGP Service Guide
"Removing the Server
A
B
AF003186
Figure 26).
"Safety
Figure 25.
