Figure 9. Configuration Jumper Descriptions - Intel SR1630GP - Server System - 0 MB RAM Service Manual

Jumper Name
BIOS Recovery
Password Clear
CMOS Clear
BMC Force Update
16
Jumper in normal position (pins 1-2) allows normal system
operation with correct BIOS settings. System will POST normally.
Jumper in maintenance mode (pins 2-3) allows Intel
password reset.
Jumper removed is used to recover from a corrupted BIOS.
Bootable media with a valid BIOS ROM required.
Jumper in normal position (pins 1-2) allows the system to
successfully POST and boot to the operating system environment.
BIOS settings are kept intact.
Jumper in clear position (pins 2-3) initiates a clearing of password.
Jumper in normal position (pins 1-2) allows the system to
successfully POST and boot to the operating system environment.
BIOS settings are kept intact.
Jumper in clear position (pins 2-3) initiates a clearing of NVRAM
following POST. A system message confirms the CMOS clear
operation was successful. This setting enforces default BIOS
settings, which you can change by entering setup pressing F2, then
exiting setup pressing F10 and saving changes.
Jumper in normal position (pins 1-2) disables BMC firmware force
update.
Jumper in clear position (pins 2-3) allows BMC firmware force
update.

Figure 9. Configuration Jumper Descriptions

®
Intel Server System SR1630GP / SR1630HGP Service Guide
Jumper Purpose
®
AMT setting/
