8. Remove the four screws that hold the optical drive to the brackets as shown in
Figure 45. Save these screws for future use.
9. If you are installing a replacement optical drive, skip the rest of these steps and
instead continue with
10. Store the brackets for future use.
11. (Optional) Install the front bezel. For instructions, see
on page
12. Install the server system cover. For instructions, see
Cover".
®
Intel Server System SR1630GP / SR1630HGP Service Guide
D

Figure 44. Removing the Optical Drive from the Server System

Figure 45. Removing the Optical Drive Brackets

"Installing a Slimline Optical
29.
C
A
B
AF000670
AF000672
Drive", Step 6 on page 55.
"Installing the Front Bezel"
"Installing the Server System
57
