3. Insert the bootable BIOS Recovery media containing the new BIOS image files. A
BIOS recovery can be accomplished from SATA CD and USB Mass Storage
device. Please note this platform does not support recovery from a USB floppy. The
recovery media must contain the following files under the root directory:
•
FVMAIN.FV
•
UEFI iFlash32
•
*Rec.CAP
•
Startup.nsh (update accordingly to use proper *Rec.CAP file)
4. Plug the system into the AC power source and power it on.
5. The BIOS POST screen will appear displaying the progress, and the system will
automatically boot to the EFI SHELL.
6. Remove the recovery media.
7. Power down and unplug the system from the AC power source.
8. Move the BIOS recovery jumper at J1F3 back to the original position, covering
storage pins 1 and 2.
9. Plug the system into the AC power source and power it up to confirm the recovery
was successful.
10. Do NOT interrupt the BIOS POST during the first boot.

Clearing the Password

If the user or administrator password(s) is lost or forgotten, moving the password clear
jumper into the "clear" position clears both passwords. Before a new password(s) is set,
you must restore the password clear jumper to its original position.
1. Power down the system and disconnect the AC power.
®
Intel Server System SR1630GP / SR1630HGP Service Guide
BIOS
Default
Recovery
2
Recover
J1F3
3

Figure 10. BIOS Recovery Jumper

AF003180
23
