Chassis Component Identification

This section helps you identify the components of your server system. If you are near the
system, you can also use the Quick Reference Label on the inside of the chassis cover to
assist in identifying components.

System Front Panel (SR1630GP)

The front of the server system includes the following buttons and LEDs.
®
Table 2. Intel
LED Color
NIC 1 / NIC 2 Green
Activity
Green
Power / Green
Sleep
Off
®
Intel Server System SR1630GP / SR1630HGP Service Guide
A
A. USB Port
B. Power Button
C. System Status LED
D. System Power LED

Figure 3. Front Controls and LEDs (SR1630GP)

Server System SR1630GP Control Panel LED Functions
State
On
Blink
On
Off
B C E
D F
E. Hard Disk Drive Activity LED
F. NIC1 LED
G. NIC2 LED
Description
NIC Link / AC is on / no access
LAN access
Power on
Power Off / ACPI S4 state
G
AF001000
5
