Intel
Server System SR1600UR
Service Guide
®
A Guide for Technically Qualified Assemblers of Intel
Identified Subassemblies/
Products
Intel Order Number E52880-004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR1600UR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel SR1600UR

Summary of Contents for Intel SR1600UR

  • Page 1 ® Intel Server System SR1600UR Service Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/ Products Intel Order Number E52880-004...
  • Page 2 Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of the Intel product could create a situation where personal injury or death may occur.

  • Page 3: Preface

    ® on the Intel Server System SR1600UR, and the location where they can be found. Chapter 2 provides a brief overview of the server system. This includes a list of the server system features, illustrations of the product, and product diagrams to help you identify components and their locations.
  • Page 4 ® Intel Server System SR1600UR Service Guide...

  • Page 5: Safety Information

    Safety Information Important Safety Instructions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the ® Intel Server Deployment Toolkit 3.0 CD and/or at http://support.intel.com/support/motherboards/server/sb/cs-010770.htm.
  • Page 6 重要安全指导 ® Intel Server System SR1600UR Service Guide...

  • Page 7: Warnings

    Take care to grip with, but not squeeze, the pliers or other tool you use to remove a jumper, or you may bend or break the pins on the board. ® Intel Server System SR1600UR Service Guide...
  • Page 8 ® viii Intel Server System SR1600UR Service Guide...

  • Page 9: Table Of Contents

    Warnings ..........................vii Chapter 1: Server System Contents and References ..........1 Server System Contents ......................1 ® Intel Server System SR1600UR Contents ..............1 ® Intel Server System SR1600URHS Contents ............. 2 Additional Information and Software ..................3 Chapter 2: Server System Features ................5 Server System Feature Overview ..................
  • Page 10 Installing and Removing a Fixed Mount Hard Drive (Fixed Mount Hard Drive System Only) . Installing a Fixed Mount Hard Disk Drive ..............58 Removing a Fixed Mount Hard Disk Drive ..............61 Installing and Removing a Hot-swap Hard Drive (Hot-swap Hard Drive System Only) ..62 ® Intel Server System SR1600UR Service Guide...
  • Page 11 Upgrading the BIOS ......................99 Preparing for the Upgrade ...................99 Upgrading the BIOS ....................100 Clearing the Password .......................100 Restoring the BIOS Defaults ....................102 Appendix A: Technical Reference ................ 105 600-W Single Power Supply Input Voltages ..............105 ® Intel Server System SR1600UR Service Guide...
  • Page 12 Site Selection ......................150 Equipment Handling Practices .................. 150 Power and Electrical Warnings ................. 151 System Access Warnings ..................152 Rack Mount Warnings ....................152 Electrostatic Discharge (ESD) ................... 153 Other Hazards ......................153 ® Intel Server System SR1600UR Service Guide...
  • Page 13 Advertencias de alimentacién y eléctricas ..............167 Advertencias sobre el cable de alimentación ............167 Advertencias el acceso al sistema ................168 Advertencias sobre el montaje en bastidor ...............169 Descarga electrostática (ESD) ..................169 Otros riesgos ......................170 ® Intel Server System SR1600UR Service Guide xiii...
  • Page 14 ® Intel Server System SR1600UR Service Guide...

  • Page 15: List Of Figures

    Figure 19. Cabling Around the Small Air Baffle (Hot-swap Hard Drive System) ..... 33 Figure 20. Front View with Bezel supporting the Standard Control Panel ......36 ® Figure 21. Front View with Bezel supporting the Intel Local Control Panel ......37 Figure 22. Installing the Front Bezel..................37 Figure 23.
  • Page 16 Figure 85. Installing the Rack Handle ..................95 Figure 86. Removing the Rack Handle ................... 96 Figure 87. Password Clear Jumper ..................101 Figure 88. BIOS Default Jumper................... 102 Figure 89. Diagnostic LED Placement Diagram ..............116 ® Intel Server System SR1600UR Service Guide...
  • Page 17 List of Tables Table 1. Server System References ..................3 ® Table 2. Intel Server System SR1600UR Feature Summary ..........6 Table 3. NIC LED Descriptions ....................24 Table 4. Setup Menu Key Use ....................97 Table 5. Power Supply Output Capability ................106 Table 6.
  • Page 18 ® xviii Intel Server System SR1600UR Service Guide...

  • Page 19: Chapter 1: Server System Contents And References

    The contents of each server system are listed below. ® Intel Server System SR1600UR Contents ® Your Intel Server System SR1600UR (fixed mount hard drive system) ships with the following items: ® • Intel Server Board S5520UR, installed in the server system •...

  • Page 20: Intel Server System Sr1600Urhs Contents

    Slimline peripheral bay filler panel, in the hardware box • Rack handles, in the hardware box • Attention document, in the server system product box • Quick Start User's Guide, in the server system product box ® Intel Server System SR1600UR Service Guide...

  • Page 21: Additional Information And Software

    Available at: http://support.intel.com/support/motherboards/server/s5520ur/ ® If you just received this Intel Server System SR1600UR Quick Start User's Guide product and you need to Available in the product box assemble your system and install components Accessories or other Intel...
  • Page 22 To make sure your system Power Budget Analysis Tool falls within the allowed Available at: power budget http://support.intel.com/support/motherboards/server/s5520ur/ ® For software to manage Intel System Management Software ® your Intel server Available at: http://www.intel.com/go/servermanagement/ ® Intel Server System SR1600UR Service Guide...

  • Page 23: Chapter 2: Server System Features

    AF002746 ® Figure 1. Intel Server System SR1600UR ® Intel Server System SR1600UR Service Guide...

  • Page 24: Server System Feature Overview

    Support for one or two Intel Xeon Processors in FC-LGA 1366 Socket B package with up to 95 W Thermal Design Power (TDP) ® • 4.8 GT/s, 5.86 GT/s and 6.4 GT/s Intel QuickPath ® Interconnect (Intel QPI) • EVRD11.1 For a complete list of supported processors, see http://support.intel.com/support/motherboards/server/s5520ur/...
  • Page 25 • Six Serial ATA (SATA) II connectors • Two I/O module connectors ® • One RMM3 connector to support an optional Intel Remote Management Module 3 • SATA Software RAID 5 Activation Key connector • One SSI-EEB compliant front panel header •...
  • Page 26 ® Table 2. Intel Server System SR1600UR Feature Summary Feature Description LEDs and displays LEDs with standard control panel: • NIC1 Activity • NIC2 Activity • Power/Sleep • System Status • System Identification • Hard Drive Activity ® Intel Light-Guided diagnostic LEDs: •...

  • Page 27: Server System Components

    This section helps you identify the components of your server system. If you are near the system, you can also use the Quick Reference Label provided on the inside of the chassis cover to assist in identifying components. ® Intel Server System SR1600UR Service Guide...

  • Page 28: Figure 2. Server System Components

    Three hot-swap drives supported in hot- swap hard drive system PCI add-in riser assembly Slimline Optical Drive Bay (drive not included) PCI card bracket (full-height) M. Front bezel (optional Processor air duct Figure 2. Server System Components ® Intel Server System SR1600UR Service Guide...

  • Page 29: Intel Light-Guided Diagnostics

    Figure 4) or hot-swap backplane (in the hot-swap hard drive system - see Figure help identify failed and failing fans. The fan fault LEDs turn on (amber) if there is a fan fault. ® Intel Server System SR1600UR Service Guide...

  • Page 30: Figure 3. Intel ® Light-Guided Diagnostic Leds - Server Board

    CPU 1 DIMM Fault LEDs CPU 2 Fan Fault LED Memory 2 Fan Fault LED CPU 2 DIMM Fault LEDs 5V Standby LED ® Figure 3. Intel Light-Guided Diagnostic LEDs - Server Board ® Intel Server System SR1600UR Service Guide...

  • Page 31: Figure 4. Intel ® Light-Guided Diagnostic Leds - Fan Board

    AF003001 Fan 1 Fault LED Fan 2 Fault LED Fan 3 Fault LED Fan 4 Fault LED Fan 5 Fault LED ® Figure 5. Intel Light-Guided Diagnostic LEDs - Hot-swap Backplane (Passive Shown) ® Intel Server System SR1600UR Service Guide...

  • Page 32: Figure 6. Intel Light-Guided Diagnostic Leds - Standard Control Panel

    AF003002 Status LED System Identification LED ® Figure 6. Intel Light-Guided Diagnostic LEDs - Standard Control Panel ® Intel Server System SR1600UR Service Guide...

  • Page 33: Server Board Components

    Server Board Components AF002696 ® Intel Server System SR1600UR Service Guide...

  • Page 34: Figure 7. Server Board Connector And Component Locations

    LCP IPMB Header SATA RAID 5 Key Header AA. SGPIO Header BB. SATA Connectors CC. I/O Module Mezzanine DD. I/O Module Mezzanine Connector 2 Connector 1 Figure 7. Server Board Connector and Component Locations ® Intel Server System SR1600UR Service Guide...

  • Page 35: Configuration Jumpers

    These pins should be jumpered on 1-2 for normal system operation. BIOS Default (J1E7) If pins 2-3 are jumpered, the BIOS settings are cleared on the next reset. These pins should be jumpered on 1-2 for normal operation. ® Intel Server System SR1600UR Service Guide...

  • Page 36: Front Of Server System

    The following figure shows the available options. TP02156 Slimline drive bay (drive not included) Control panel (Standard control panel shown) Hard Drive Status LEDs (hot-swap drives only) Hard drive bays (drives not included) Figure 9. Optional Peripherals ® Intel Server System SR1600UR Service Guide...

  • Page 37: Hard Disk Drive Carriers

    Hard Disk Drive Carriers The fixed mount hard drive server system (Product Code: SR1600UR) ships with three fixed mount drive carriers for installing three SATA hard drives. The hot-swap hard drive server system (Product Code: SR1600URHS) ships with three hot-swap drive carriers for installing three SAS or Serial ATA (SATA) drives. The leftmost hard drive bay can be used to support a USB floppy drive this system.

  • Page 38: Control Panel

    Control Panel ® The Intel Server System SR1600UR supports the following types of control panels: • Standard Control Panel ® • Intel Local Control Panel (hot-swap hard drive systems only) Standard Control Panel The following diagram identifies the features available on the standard control panel. For instructions on installing the standard control panel, see “Replacing the Control Panel...

  • Page 39: Figure 10. Standard Control Panel

    Figure 10. Standard Control Panel ® Intel Local Control Panel ® The following diagram identifies the features available on the Intel Local Control Panel. ® Note: The Intel Local Control Panel is only supported in the hot-swap hard drive system (Product Code: SR1600URHS).

  • Page 40: Figure 11. Intel ® Local Control Panel

    No light indicates no hard disk drive activity. Reset Button Reboots and initializes the system. USB Port Allows you to attach a USB component to the front of the system. ® Figure 11. Intel Local Control Panel ® Intel Server System SR1600UR Service Guide...

  • Page 41: Bezels

    The order numbers for the bezels are: • ADWBEZBLACK: Black bezel for use with the standard control panel. ® • ADWLCDBEZEL: Black bezel for use with the Intel Local Control Panel. Rear of Server System G F E D AF002731...

  • Page 42: Back Panel Connectors

    No network connection Solid Amber Network connection in place Blinking Amber Transmit/receive activity Right 10 Mbps connection (if left LED is on or blinking) Solid Amber 100 Mbps connection Solid Green 1000 Mbps connection ® Intel Server System SR1600UR Service Guide...

  • Page 43: Sas/Sata Backplanes

    SW RAID Activation Key Fan 1 Power Fan 5 Power Screw Bridge Board Connector Front Panel USB Fan 4 Power M. Hot-swap SAS/SATA Connectors Fan 3 Power Figure 14. Active SAS Backplane Components ® Intel Server System SR1600UR Service Guide...

  • Page 44: Passive Backplane

    Fan 1 Power SATA 1 Screw Fan 5 Power M. Front Panel USB Bridge Board Connector SATA 2 Fan 4 Power Hot-swap SAS/SATA Connectors Fan 3 Power Figure 15. Passive SAS/SATA Backplane Components ® Intel Server System SR1600UR Service Guide...

  • Page 45: Raid Support

    “Configure SATA as RAID”. The Intel Embedded Server RAID Technology II is ® enabled by the “Configure SATA as RAID” option. The Intel Embedded Server RAID Technology II feature provides RAID modes 0, 1, and 10. For RAID 0, 1, and 10, enclosure management is provided over the bridge board.

  • Page 46: Rack Mount Options

    (19 inches by upto 30 inches deep) EIA-310D compatible server cabinet. When installing the system into a rack, Intel recommends you install systems from the bottom of the rack to the top. In other words, install the first system in the rack into the bottom position of the rack, the second system in the second position from the bottom, and so on.

  • Page 47: Chapter 3: Hardware Installations And Upgrades

    Antistatic wrist strap and conductive foam pad (recommended) System References All references to left, right, front, top, and bottom assume the reader is facing the front of the server system as it would be positioned for normal operation. ® Intel Server System SR1600UR Service Guide...

  • Page 48: Cable Routing

    SATA Data to Fixed HDD 2 Optical Control SATA Data to Optical Drive Drive Panel Module Module Power to Optical Drive Drive Bays AF002876 Figure 16. Cable Routing (Fixed Mount Hard Drive System) ® Intel Server System SR1600UR Service Guide...

  • Page 49: Figure 17. Cabling Around The Small Air Baffle (Fixed Mount Hard Drive System)

    Optical Drive Data Cable • SATA 0-2 HDD Data Cables • SATA 0-2 HDD Power Cables Front Standoff Detail AF002878 Figure 17. Cabling Around the Small Air Baffle (Fixed Mount Hard Drive System) ® Intel Server System SR1600UR Service Guide...

  • Page 50: Hot-Swap Hard Drive System

    Hot-swap Hard Drive System Use the following figure to determine the correct cable routing for a hot-swap hard drive system. Server Board CPU1 Intel® Remote Management Module 3 (optional) Power Supply I/O Module (optional) Power Supply Bridge Board Backplane Board (Passive shown) CPU2 Power to Server Board (Aux.

  • Page 51: Removing And Installing From A Rack

    Figure 19. Cabling Around the Small Air Baffle (Hot-swap Hard Drive System) Removing and Installing from a Rack ® ® To install the Intel Server System SR1600UR in a rack, three Intel rack options are available: • Fixed mount relay rack/cabinet mount kit This rack option requires the system to removed from the rack before servicing.

  • Page 52: Fixed Bracket Rack Mount Removal

    16. In a similar manner to steps 13 through 15, install a screw through a slot in the outer rail and into the rear-most threaded hole in the front bracket. Firmly tighten this screw. 17. Firmly tighten the front screw installed loosely in step 15. ® Intel Server System SR1600UR Service Guide...

  • Page 53: Basic Rail Rack Mount Removal

    5. Insert the inner rails over the server chassis sidewall studs. 6. Slide the inner rails toward the front of the server chassis. 7. Secure the inner rails with one #6-32 x 1/4 screw for each rail. ® Intel Server System SR1600UR Service Guide...

  • Page 54: Tool-Less Rail Rack Mount Servicing

    Note: Beware of cables when re-installing the system into the rack so that the cables do not get pulled or interfered with. Installing and Removing the Front Bezel ® The front bezels are available as optional accessories for the Intel Server System SR1600UR. The following front bezel options are available: •...

  • Page 55: Installing The Front Bezel

    TP02198 ® Figure 21. Front View with Bezel supporting the Intel Local Control Panel Installing the Front Bezel Before installing the bezel, you must install the rack handles. For instructions, see “Installing the Rack Handles” on page To install the front bezel, follow these steps: 1.

  • Page 56: Removing The Front Bezel

    24), slide the top cover back until it stops (see letter "C" in Figure 24). 3. Insert your finger in the notch (see letter “D” in Figure 24) and lift the cover upward to remove it. ® Intel Server System SR1600UR Service Guide...

  • Page 57: Installing The System Cover

    2. Slide the cover forward until it clicks into place (see letter “A” in Figure 25). 3. (Optional) Insert the safety screw at the center of the top cover (see letter “B” in Figure 25) if required. ® Intel Server System SR1600UR Service Guide...

  • Page 58: Figure 25. Installing The Server System Cover

    TP02196 Figure 25. Installing the Server System Cover ® Intel Server System SR1600UR Service Guide...

  • Page 59: Removing And Installing The Pci Riser Assembly

    — If you need to add or replace a PCI add-in card, see “Installing and Removing a PCI Add-in Card” on page — If you need to add or replace a PCI riser connector, see “Replacing a PCI Riser Card” on page ® Intel Server System SR1600UR Service Guide...

  • Page 60: Installing The Pci Riser Assembly

    The riser card seats into the matching sockets on the server board. 4. Connect any cables to add-in cards that require them. See your add-in card documentation for information and add-in card requirements. ® Intel Server System SR1600UR Service Guide...

  • Page 61: Replacing A Pci Riser Card

    7. Install the PCI riser assembly into the server system. For instructions, see “Installing the PCI Riser Assembly” on page 8. Connect any cables to add-in cards that require them. See your add-in card documentation for information and add-in card requirements. ® Intel Server System SR1600UR Service Guide...

  • Page 62: Installing The Replacement Pci Express* Riser Card

    The instructions below describe how to install and remove a PCI add-in card. Installing a PCI Add-in Card To install a PCI add-in card, follow these steps: 1. Remove the PCI riser assembly. For instructions, see “Removing the PCI Riser Assembly” on page ® Intel Server System SR1600UR Service Guide...

  • Page 63: Removing A Pci Add-In Card

    2. Remove the screw securing the add-in card to the add-in card slot (see letter “A” in Figure 31) . 3. Remove the PCI add-in card from the riser card connector (see letter “B” in Figure 31). ® Intel Server System SR1600UR Service Guide...

  • Page 64: Removing And Installing The Processor Air Duct

    To remove the processor air duct, follow these steps: 1. Remove the PCI riser assembly. For instructions, see “Removing the PCI Riser Assembly” on page 2. Lift the processor air duct from its location over the two processor sockets. ® Intel Server System SR1600UR Service Guide...

  • Page 65: Installing The Processor Air Duct

    The silkscreen on the board displays DIMM A1, DIMM A2, DIMM B1, DIMM B2, DIMM C1, DIMM C2 for DIMMs on CPU socket 1 and DIMM D1, DIMM D2, DIMM E1, DIMM E2, DIMM F1, DIMM F2 for DIMMs on CPU socket 2. ® Intel Server System SR1600UR Service Guide...

  • Page 66: Dimm Blank Installation Requirements

    CPU 1 DIMM slots. ® For additional information regarding memory requirements and options, refer to the Intel Server System SR1600UR Technical Product Specification. For a web link to the list of tested DIMMs, see “Additional Information and Software” on page...

  • Page 67: Figure 34. Installing The Memory

    8. When the DIMM is correctly positioned, push down on the top edge of the DIMM until the retaining clips snap into place (see letter “C” in Figure 34). 9. Make sure the clips are firmly in place (see letter “D” in Figure 34). ® Intel Server System SR1600UR Service Guide...

  • Page 68: Removing Dimms

    5. Push the lever handle down and away from the socket to release it (see letter “A” in Figure 35). 6. Rotate the lever open all the way (see letter “B” in Figure 35). ® Intel Server System SR1600UR Service Guide...

  • Page 69: Figure 35. Lifting The Processor Socket Lever

    Note: Do not touch the orientation posts on the socket; they are very sensitive and easily damaged. Note: Retain the protective socket cover for use when removing a processor that will not be replaced. ® Intel Server System SR1600UR Service Guide...

  • Page 70: Figure 37. Removing The Protective Socket Cover

    11. Orient the processor with the socket such that the orientation notches on the processor align with the two orientation posts on the socket, and insert the processor into the socket (see Figure 39). ® Intel Server System SR1600UR Service Guide...

  • Page 71: Installing The Heatsink

    Note: New unused heatsinks have adequate TIM on the bottom. If you are reusing a heatsink from replacing a processor, make sure there is adequate TIM present on the heatsink to support processor cooling. ® Intel Server System SR1600UR Service Guide...

  • Page 72: Figure 41. Installing The Heatsink (1U Passive Heatsink Shown)

    Repeat steps 4a through 4c by giving each screw two rotations each time until all screws are lightly tightened upto a maximum of 8 inch-lbs torque. AF002841 Figure 41. Installing the Heatsink (1U Passive Heatsink Shown) ® Intel Server System SR1600UR Service Guide...

  • Page 73: Removing The Heatsink

    Lift the heatsink from the processor. If it does not pull up easily, twist the heatsink again. Do not force the heatsink from the processor. Doing so could damage the processor. ® Intel Server System SR1600UR Service Guide...

  • Page 74: Removing The Processor

    6. Open the CPU load plate (see Figure 36). 7. Remove the processor. 8. If installing a replacement processor, see “Installing the Processor” on page 50 instructions. Otherwise, install the protective socket cover over the empty processor socket. ® Intel Server System SR1600UR Service Guide...

  • Page 75: Removing And Installing The Small Air Baffle

    To install the small air baffle, follow these steps: 1. Lower the baffle into the server system and position the baffle over the two standoff locations. 2. Snap the baffle into place as shown in Figure ® Intel Server System SR1600UR Service Guide...

  • Page 76: Installing A Fixed Mount Hard Disk Drive

    AC power cord from the system or wall outlet. ® You can install up to three fixed SATA hard drives in the Intel Server System SR1600UR (Product Code: SR1600UR).

  • Page 77: Figure 45. Removing Fixed Mount Drive Carrier From The Server System

    7. Align the holes in the hard disk drive to the holes in the drive carrier and attach it to the carrier with the screws that were attached to the plastic retention device (see Figure 47). ® Intel Server System SR1600UR Service Guide...

  • Page 78: Figure 47. Installing Fixed Hard Drive Into The Carrier

    10. Connect the opposite end of the SATA data cable(s) to the hard drive(s) (see letter “B” in Figure 48). 11. Connect the SATA power connector(s) to each installed hard drive (see letter “C” in Figure 48). Cable Connector AF003018 ® Intel Server System SR1600UR Service Guide...

  • Page 79: Removing A Fixed Mount Hard Disk Drive

    Note: To maintain proper system cooling, all hard drive carriers must be installed in the server system and populated with either a drive or a drive blank. 5. Slide the hard drive carrier into the server system until it clicks into place. ® Intel Server System SR1600UR Service Guide...

  • Page 80: Installing And Removing A Hot-Swap Hard Drive (Hot-Swap Hard Drive System Only)

    Installing and Removing a Hot-swap Hard Drive (Hot- swap Hard Drive System Only) ® You may install up to three hot-swap SAS or SATA drives in the Intel Server System SR1600UR (Product Code: SR1600URHS). Cautions: If you install less than three drives or devices, the empty drive bays must be occupied by carriers with baffles to maintain proper system cooling.

  • Page 81: Figure 51. Removing Retention Device From Drive Carrier

    (see letter “A” in Figure 53). 9. Close the lever to lock the drive assembly into place (see letter “B” in Figure 53). AF002946 Figure 53. Installing Drive Assemby into the Server System ® Intel Server System SR1600UR Service Guide...

  • Page 82: Removing A Hot-Swap Sas Or Sata Hard Disk Drive

    To maintain proper system cooling, a filler blank must be installed if you do not install a device at this location. ® Note: A USB Floppy drive is not supported in the Intel Server System SR1600UR with fixed mount hard drives (Product Code: SR1600UR).

  • Page 83: Installing A Slimline Optical Drive Or Internal Usb Floppy

    Push the device all the way from the front until it clicks (see letter “C” in Figure 55). 8. Verify that the blue release lever on the tray (see letter “D” in Figure 55) locks into place. ® Intel Server System SR1600UR Service Guide...

  • Page 84: Figure 55. Installing An Optical Drive Assembly Into The Server System

    9. Connect the SATA end of the cable to one of the SATA connectors on the server board (see letter “B” in Figure 56). Server Board Server Board SATA Connectors SATA Cable SATA Conn. Detail AF002889 Figure 56. Connecting the Optical Device Data Cable ® Intel Server System SR1600UR Service Guide...

  • Page 85: Removing A Slimline Optical Drive Or Internal Usb Floppy

    (see letter “B” in Figure 58). 5. Slide the optical drive out (see letter “C” in Figure 58) to remove it from the tray. ® Intel Server System SR1600UR Service Guide...

  • Page 86: Filling Empty Server System Bays

    • If you do not have a hard drive installed, install the drive blank into the hard drive carrier. • Install empty hard drive carriers into any remaining empty hard drive bays. ® Intel Server System SR1600UR Service Guide...

  • Page 87: Installing And Removing The I/O Expansion Module

    6. First fit the front of the module into the back panel slot(s), and then attach the module to the server board connector and engage the standoffs (see letter “C” in Figure 59). ® Intel Server System SR1600UR Service Guide...

  • Page 88: Removing The I/O Expansion Module

    3. Disconnect the I/O expansion module from the server board connector and the standoffs and remove the module out of the server system (see letter “A” in Figure 60). 4. Remove the standoffs from the server board (see letter “B” in Figure 60). ® Intel Server System SR1600UR Service Guide...

  • Page 89: Installing And Removing The Intel ® Remote Management Module 3

    Remote Management Module 3, follow these steps: 1. Remove the PCI riser assembly. For instructions, see “Removing the PCI Riser Assembly” on page 2. Remove the processor air duct. For instructions, see “Removing the Processor Air Duct” on page ® Intel Server System SR1600UR Service Guide...

  • Page 90: Figure 61. Removing The Intel ® Rmm3 Filler Panel

    ® 3. Squeeze the sides of the Intel RMM3 filler panel to disengage it from the server system back panel and remove it (see Figure 61). AF002997 ® Figure 61. Removing the Intel RMM3 filler panel ® 4. Attach the Intel...

  • Page 91: Figure 63. Connecting The Intel ® Rmm3 Cable

    8. Install the processor air duct. For instructions, see “Installing the Processor Air Duct” on page 9. Install the PCI riser assembly into the server system. For instructions, see “Installing the PCI Riser Assembly” on page ® Intel Server System SR1600UR Service Guide...

  • Page 92: Rmm3

    RMM3 from the connector on the server board (see letter “B” Figure 65) and remove the module out of the server system (see letter “C” in Figure 65). AF002858 ® Figure 65. Removing the Intel RMM3 from the Server System ® Intel Server System SR1600UR Service Guide...

  • Page 93: Removing And Installing The Fan Board (Fixed Mount Hard Drive System Only)

    ® The Intel Server System SR1600UR with fixed mount hard drives (Product Code: SR1600UR) includes a fan board. The following sections describe how to replace the fan board. Removing the Fan Board To remove the fan board, follow these steps: 1.

  • Page 94: Figure 67. Removing The Fan Board From The Server System

    7. Lift the fan board out of the server system (see letter “D” in Figure 67). AF002905 Figure 67. Removing the Fan Board from the Server System 8. Install a replacement fan board. For instructions, see “Installing the Fan Board” on page ® Intel Server System SR1600UR Service Guide...

  • Page 95: Installing The Fan Board

    5. Install the processor air duct. For instructions, see “Installing the Processor Air Duct” on page 6. Install the PCI riser assembly into the server system. For instructions, see “Installing the PCI Riser Assembly” on page ® Intel Server System SR1600UR Service Guide...

  • Page 96: Installing And Removing The Backplane Board (Hot-Swap Hard Drive System Only)

    Installing and Removing the Backplane Board (Hot- swap Hard Drive System Only) ® The Intel Server System SR1600UR with hot-swap drives (Product Code: SR1600URHS) requires that you install a hot-swap backplane to make the system operational. Two backplane options are supported: •...

  • Page 97: Figure 69. Installing The Backplane Into The Server System

    Insert the bridge board into the bridge board connector on the backplane and server board (see letter “B” in Figure 70). Make sure that the connector edges on both sides align correctly with the slots. ® Intel Server System SR1600UR Service Guide...

  • Page 98: Figure 70. Installing The Bridge Board

    (see letter “B” in Figure 71). 10. Connect the power cable to the power connector on the backplane (see letter “C” in Figure 71). 11. Passive backplane only: Do the following: ® Intel Server System SR1600UR Service Guide...

  • Page 99: Figure 71. Making Cable Connections

    12. Install the processor air duct. For instructions, see “Installing the Processor Air Duct” on page 13. Install the PCI riser assembly into the server system. For instructions, see “Installing the PCI Riser Assembly” on page ® Intel Server System SR1600UR Service Guide...

  • Page 100: Removing The Backplane Board

    5. Loosen the thumbscrew on the backplane board (see letter “A” in Figure 73). 6. Hold the backplane board only by the edges and slide the backplane board in the direction shown to release it (see letter “B” in Figure 73). ® Intel Server System SR1600UR Service Guide...

  • Page 101: Figure 73. Removing The Backplane From The Server System

    (see letter “D” in Figure 73). AF002904 Figure 73. Removing the Backplane from the Server System 8. Install a replacement backplane. For instructions, see “Installing the Backplane Board” on page ® Intel Server System SR1600UR Service Guide...

  • Page 102: Removing And Installing The Server Board

    Heatsink” on page 11. Remove the nine screws from the server board (see letter “A” in Figure 74) and lift the server board from the server system (see letter “B” in Figure 74). ® Intel Server System SR1600UR Service Guide...

  • Page 103: Installing The Server Board

    1. Place the server board into the server system (see letter “A” in Figure 75). 2. Attach the server board with screws at the nine locations identified by black arrows (see letter “B” in Figure 75). ® Intel Server System SR1600UR Service Guide...

  • Page 104: Figure 75. Installing The Server Board

    10. Install the blue air baffle. For instructions, see “Installing the Small Air Baffle” on page 11. If necessary, install the I/O expansion module. For instructions, see “Installing the I/O Expansion Module” on page ® Intel Server System SR1600UR Service Guide...

  • Page 105: Replacing The Backup Battery

    ® ® 12. If necessary, install the Intel RMM3. For instructions, see “Installing the Intel RMM3” on page 13. Install the processor air duct. For instructions, see “Installing the Processor Air Duct” on page 14. Install the PCI riser assembly. For instructions, see “Installing the PCI Riser...

  • Page 106: Replacing The Power Supply

    1. Disconnect all power cables. 2. Lift the power supply to disengage it from the latch (see letter “A” in Figure and remove the power supply by sliding it out (see letter “B” in Figure 77). ® Intel Server System SR1600UR Service Guide...

  • Page 107: Replacing The Control Panel Module (Hot-Swap Hard Drive System Only)

    1. Unplug the front panel and USB cables from the backplane (see letters “A” and “B” Figure 79). 2. Press the latch at the back of the control panel and push it forward (see letter “C” in Figure 79). ® Intel Server System SR1600UR Service Guide...

  • Page 108: Figure 79. Removing The Standard Control Panel Module

    7. Connect the two cables to the USB and front panel connectors on the backplane (see letters “E” and “F” in Figure 80). AF002950 Figure 80. Installing Control Panel Module into the Server System ® Intel Server System SR1600UR Service Guide...

  • Page 109: Removing And Installing The Fan Assembly

    5. Disconnect the fan power cables from the backplane board (see letter “A” in Figure 81). 6. Press latch (see letter “B” in Figure 81) and slide fan assembly to the left (see letter “C” in Figure 81). ® Intel Server System SR1600UR Service Guide...

  • Page 110: Installing The System Fan Assembly

    To install the system fan assembly, follow these steps: 1. Lower the system fan assembly into place (see letter “A” in Figure 82) and slide it to the right (see letter “B” in Figure 82). ® Intel Server System SR1600UR Service Guide...

  • Page 111: Figure 82. Installing The System Fan Assembly

    5. Install the processor air duct. For instructions, see “Installing the Processor Air Duct” on page 6. Install the PCI riser assembly. For instructions, see “Installing the PCI Riser Assembly” on page ® Intel Server System SR1600UR Service Guide...

  • Page 112: Replacing A System Fan

    ® The system fans at the front of the Intel Server System SR1600UR can be individually replaced if one of them fails. Use the following steps to replace a dual rotor fan.

  • Page 113: Installing And Removing The Rack Handles

    Align the rack handle with the two holes on the side of the server system and attach the rack handle to the server system with two screws as shown in Figure AF000377 Figure 85. Installing the Rack Handle ® Intel Server System SR1600UR Service Guide...

  • Page 114: Removing The Rack Handles

    Removing the Rack Handles Remove the two screws holding the rack handle in place, and remove the rack handle from the server system as shown in Figure AF000378 Figure 86. Removing the Rack Handle ® Intel Server System SR1600UR Service Guide...

  • Page 115: Chapter 4: Server Utilities

    This section describes the BIOS Setup Utility options, which is used to change server configuration defaults. You can run BIOS Setup with or without an operating system ® being present. For information about specific BIOS setup screens, see the Intel Server Board S5520UR Technical Product Specification. See “Additional Information and...
  • Page 116 If "No" is selected and the <Enter> key is pressed, or if the <Esc> key is pressed, you are returned to the screen you were in before <F9> was pressed without affecting any existing field values. ® Intel Server System SR1600UR Service Guide...

  • Page 117: Upgrading The Bios

    Recording the Current BIOS Settings 1. Boot the computer and press <F2> when you see the message: Press <F2> Key if you want to run SETUP 2. Write down the current settings in the BIOS Setup program. ® Intel Server System SR1600UR Service Guide...

  • Page 118: Upgrading The Bios

    3. Locate the Password Clear jumper block at board position J1E8. 4. Move the jumper from the normal operation position, that is, Password Clear Protect position (covering pins 1 and 2) to the Password Clear Erase position (covering pins 2 and 3). ® Intel Server System SR1600UR Service Guide...

  • Page 119: Figure 87. Password Clear Jumper

    6. Return the Password Clear jumper to the Password Clear Protect position (covering pins 1 and 2). 7. Close the server system. 8. Power up the server. The password is now cleared and can be reset by going into BIOS setup. ® Intel Server System SR1600UR Service Guide...

  • Page 120: Restoring The Bios Defaults

    Figure 88. BIOS Default Jumper 5. Wait five seconds. 6. Return the BIOS Default jumper to the normal position (covering pins 1 and 2). 7. Close the server system. 8. Power up the system. ® Intel Server System SR1600UR Service Guide...
  • Page 121 The BIOS defaults settings are now restored and can be reset by going into the BIOS setup. ® Intel Server System SR1600UR Service Guide...
  • Page 122 ® Intel Server System SR1600UR Service Guide...

  • Page 123: Appendix A: Technical Reference

    2. Maximum input current at high input voltage range is measured at 180 VAC, at maximum load. 3. This is not to be used for determining agency input current markings. 4. Maximum rated input current is measured at 100 VAC and 200 VAC. ® Intel Server System SR1600UR Service Guide...

  • Page 124: 600-W Single Power Supply Output Voltages

    Warning: Do not exceed a combined power output of 90 Watts for the +5 V and +3.3 V outputs. Exceeding a combined 90 Watts will overload the power subsystem and may cause the power supplies to overheat and malfunction. ® Intel Server System SR1600UR Service Guide...

  • Page 125: System Environmental Specifications

    Acoustic noise Sound Power: 7.0 BA in an idle state at typical office ambient temperature (23 +/- 2°C). ® Electrostatic +/-15 KV except I/O port +/- 8 KV per Intel Environment test specification. discharge (ESD) System Cooling 2550 BTU/Hr Requirement in BTU/Hr ®...
  • Page 126 ® Intel Server System SR1600UR Service Guide...

  • Page 127: Appendix B: Intel Server Issue Report Form

    System BIOS Version: ® Intel Remote Management Module Firmware Version (if applicable): ® Intel Management Module BMC Revision (if applicable) : BMC/mBMC Version: FRU/SDR Version: HSC Version: Has the latest BIOS been tried? (Yes/No): ® Intel Server System SR1600UR Service Guide...
  • Page 128 Thermal Solution Processor 1 Processor 2 Processor 3 Processor 4 Thermal solution (Heatsink) examples: (1U, Passive w/air ducting, Active w/fan, etc.) =============================================================== Memory: Manufacturer Part Number DRAM Part Number On Intel tested list? ® Intel Server System SR1600UR Service Guide...
  • Page 129 Operating System Information (Example: RedHat* Enterprise Linux, Microsoft* Windows* Server 2003, Service pack 1, OEM CD): Manufacturer: Version: Language version (English, Arabic, Chinese (Simplified)): Service Pack Level or Kernel Revision: Distribution (OEM/Retail): =============================================================== ® Intel Server System SR1600UR Service Guide...
  • Page 130 Has the latest RAID driver been tried? (Yes/No): RAID volumes configuration (disks & RAID level): RAID volume use (Boot device/Data Volume): Is BBU (Battery Backup Unit) installed? (Yes/No): BBU part number: =============================================================== Detailed description of issue: Troubleshooting tried: ® Intel Server System SR1600UR Service Guide...
  • Page 131 =============================================================== Issue impact statements: Do you have any potential Intel system, or component purchases that this issue is holding up? If yes, please provide a brief description below. Do you have systems already purchased that are not being delivered to your customers because of this issue? If yes, please provide a brief description below.
  • Page 132 ® Intel Server System SR1600UR Service Guide...

  • Page 133: Appendix C: Led Decoder

    The two are concatenated as ACh. Table 7. POST Progress Code LED Example Upper Nibble LEDs Lower Nibble LEDs LEDs LED #7 LED #6 LED #5 LED #4 LED #3 LED #2 LED #1 LED #0 Status Result ® Intel Server System SR1600UR Service Guide...

  • Page 134: Figure 89. Diagnostic Led Placement Diagram

    SPD bad so no memory could be detected OxEAh Channel Training Error: DQ/DQS training failed on a channel during memory channel initialization. 0xEBh Memory Test Error: memory failed Hardware BIST. ® Intel Server System SR1600UR Service Guide...
  • Page 135 0x04h Early processor initialization where system BSP is selected 0x10h Power-on initialization of the host processor (bootstrap processor) 0x11h Host processor cache initialization (including AP) 0x12h Starting application processor initialization 0x13h SMM initialization ® Intel Server System SR1600UR Service Guide...
  • Page 136 Reserved for PCI bus 0x54h Reserved for PCI bus 0x55h Reserved for PCI bus 0x56h Reserved for PCI bus 0x57h Reserved for PCI bus 0x58h Resetting USB bus 0x59h Reserved for USB devices ® Intel Server System SR1600UR Service Guide...
  • Page 137 0x91h Disabling the keyboard 0x92h Detecting the presence of the keyboard 0x93h Enabling the keyboard 0x94h Clearing keyboard input buffer 0x95h Instructing keyboard controller to run Self Test (PS2 only) Mouse (USB only) ® Intel Server System SR1600UR Service Guide...
  • Page 138 Trying to boot device selection 1 0xD2 Trying to boot device selection 2 0xD3 Trying to boot device selection 3 0xD4 Trying to boot device selection 4 0xD5 Trying to boot device selection 5 ® Intel Server System SR1600UR Service Guide...
  • Page 139 Driver Execution Environment (DXE) Core (not accompanied by a beep code) 0xE4h Entered EFI driver execution (DXE) phase 0xE5h Started dispatching drivers 0xE6h Started connecting drivers DXE Drivers 0xE7h Waiting for user input ® Intel Server System SR1600UR Service Guide...
  • Page 140 0x31h Crisis recovery has been initiated by software (corrupt flash) 0x34h Loading crisis recovery capsule 0x35h Handing off control to the crisis recovery capsule 0x3Fh Unable to complete crisis recovery capsule ® Intel Server System SR1600UR Service Guide...

  • Page 141: Appendix D: Getting Help

    — A searchable knowledgebase to search for product information throughout the support site 2. If you are still unable to obtain a solution to your issue, send an email to Intel’s technical support center using the online form available at http://supportmail.intel.com/scripts-emf/welcome.aspx...
  • Page 142 ® Intel Server System SR1600UR Service Guide...

  • Page 143: Appendix E: Regulatory And Certification Information

    (or higher) and operating at the same (or higher) speed as the microprocessor used on this server board. The final configuration of your end system product may require additional EMC compliance testing. For more information, please contact your local Intel representative.

  • Page 144: Product Emc Compliance - Class A Compliance

    AS/NZS 3548 Emissions (Australia/New Zealand) • BSMI CNS13438 Emissions (Taiwan) • GOST R 29216-91 Emissions (Russia) • GOST R 50628-95 Immunity (Russia) • Belarus Certification (Belarus) • Ukraine Certification (Ukraine) • KCC Certification (EMI) (Korea) ® Intel Server System SR1600UR Service Guide...

  • Page 145: Product Ecology Compliance

    Product Ecology Compliance Intel has a system in place to restrict the use of banned substances in accordance with world wide regulatory requirements. A Material Declaration Data Sheet is available for Intel products. For more reference on material restrictions and compliance you can view Intel's Environmental Product Content Specification at http://supplier.intel.com/ehs/environmental.htm.

  • Page 146: Product Regulatory Compliance Markings

    Product Regulatory Compliance Markings This Intel Server Chassis product if provided with the following regulatory and safety markings. In the event there is no room for a marking(s) on the chassis, the information is provided here in this guide. Table 9. Product Regulatory Compliance Markings...
  • Page 147 GOST R Marking Russia KCC Mark (Korean Korea Communications Comission Belarus Safety Belarus Compliance Mark Waste of Electronic Europe and Electrical Equipment Recycling Mark China Restriction of China Hazardous Substance Environmental Friendly Use Period Mark ® Intel Server System SR1600UR Service Guide...
  • Page 148 This notice is required by California Code of Regulations, Title 22, Division 4.5, and Chapter 33: Best Management Practices for Perchlorate Materials. This product may include a battery which contains Perchlorate material. ® Intel Server System SR1600UR Service Guide...
  • Page 149 "WARNING:" Proper Ground "Apparaten skall anslutas till jordat uttag, när Outlet den ansluts till ett nätverk." "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan." "Connect only to a properly earth grounded outlet." Safety Stand-by power ® Intel Server System SR1600UR Service Guide...

  • Page 150: Rack Mount Installation Guidelines

    Location in accordance with articles 110-16, 110-17, and 110-18 of the National Electric Code, ANSI/NFPA 70. The DC source must be electrically isolated by double or reinforced insulation from any hazardous AC source. ® Intel Server System SR1600UR Service Guide...

  • Page 151: Power Cord Usage Guidelines

    Connector, server end: The connectors that plug into the AC receptacle on the server must be an approved IEC (International Electrotechnical Commission) 320, sheet C13, type female connector. • Cord length and flexibility: Cords must be less than 4.5 meters (14.76 feet) long. ® Intel Server System SR1600UR Service Guide...

  • Page 152: Electromagnetic Compatibility Notices

    All cables used to connect to peripherals must be shielded and grounded. Operation with cables, connected to peripherals that are not shielded and grounded may result in interference to radio and TV reception. ® Intel Server System SR1600UR Service Guide...

  • Page 153: Ices-003 (Canada)

    Install and use the equipment according to the instruction manual. BSMI (Taiwan) The BSMI Certification Marking and EMC warning is located on the outside rear area of the product. ® Intel Server System SR1600UR Service Guide...

  • Page 154: Kcc (Korea)

    Updated product information for configurations can be found on the Intel Server Builder Web site at the following URL: http://channel.intel.com/go/serverbuilder If you do not have access to Intel's Web address, please contact your local Intel representative. • Server Chassis: (base chassis is provided with power supply and fans) - UL listed.

  • Page 155: Appendix F: Installation/Assembly Safety Instructions

    5. Provide some electrostatic discharge (ESD) protection by wearing an antistatic wrist strap attached to chassis ground of the system-any unpainted metal surface-when handling components. 6. Do not operate the system with the chassis covers removed. ® Intel Server System SR1600UR Service Guide...
  • Page 156 • Provided with a properly grounded wall outlet. • Provided with sufficient space to access the power supply cord(s), because they serve as the product's main power disconnect. ® Intel Server System SR1600UR Service Guide...

  • Page 157: Deutsch

    Anschlußkabel von den I/O Anschlüssen oder Ports ab. 5. Tragen Sie ein geerdetes Antistatik Gelenkband, um elektrostatische Ladungen (ESD) über blanke Metallstellen bei der Handhabung der Komponenten zu vermeiden. 6. Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein. ® Intel Server System SR1600UR Service Guide...
  • Page 158 Schutzhandschuhe tragen. Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers entsprechend. ® Intel Server System SR1600UR Service Guide...

  • Page 159: Français

    C'est le câble d'alimentation qui est considéré comme le moyen de se déconnecter du CA. La prise à laquelle le système est branché doit se situer à proximité de l'équipement et être facilement accessible. ® Intel Server System SR1600UR Service Guide...
  • Page 160 Le microprocesseur et le dissipateur de chaleur peuvent être chauds si le système a été sous tension. Faites également attention aux broches aiguës des cartes et aux bords tranchants du capot. Nous vous recommandons l'usage de gants de protection. ® Intel Server System SR1600UR Service Guide...

  • Page 161: Español

    No intente modificar ni usar el cable de alimentación de corriente alterna, si no corresponde exactamente con el tipo requerido. El número de cables suministrados se corresponden con el número de fuentes de alimentación de corriente alterna que tenga el producto ® Intel Server System SR1600UR Service Guide...
  • Page 162 4. Inserte el bloqueo de seguridad en el sistema y bloquéelo para impedir que pueda accederse al mismo sin autorización. 5. Conecte todos los cables externos y los cables de alimentación CA al sistema. ® Intel Server System SR1600UR Service Guide...

  • Page 163: Italiano

    éstos hacen de medio principal de desconexión del sistema. Italiano Rivolgersi ad un tecnico specializzato per la riparazione dei componenti dell'alimentazione di questo prodotto. È possibile che il prodotto disponga di più fonti di alimentazione. ® Intel Server System SR1600UR Service Guide...
  • Page 164 4. Inserire e chiudere a chiave il lucchetto sul retro del sistema per impedire l'accesso non autorizzato al sistema. 5. Ricollegare tutti i cavi esterni e le prolunghe AC del sistema. ® Intel Server System SR1600UR Service Guide...
  • Page 165 • "Dotata di una presa a muro correttamente installata. • "Dotata di spazio sufficiente ad accedere ai cavi di alimentazione, i quali rappresentano il mezzo principale di scollegamento del sistema. ® Intel Server System SR1600UR Service Guide...
  • Page 166 ® Intel Server System SR1600UR Service Guide...

  • Page 167: Appendix G: Safety Information

    To reduce the risk of bodily injury, electrical shock, fire, and equipment damage, read this document and observe all warnings and precautions in ® this guide before installing or maintaining your Intel server product. In the event of a conflict between the information in this document and information provided with the product or on the website for a particular product, the product documentation takes precedence.

  • Page 168: Intended Application Uses

    Conform to local occupational health and safety requirements when moving and lifting equipment. • Use mechanical assistance or other suitable assistance when moving and lifting equipment. • To reduce the weight for easier handling, remove any easily detachable components. ® Intel Server System SR1600UR Service Guide...

  • Page 169: Power And Electrical Warnings

    The power supply cord(s) is/are the main disconnect device to AC power. The socket outlet(s) must be near the equipment and readily accessible for disconnection. • The power supply cord(s) must be plugged into socket-outlet(s) that is /are provided with a suitable earth ground. ® Intel Server System SR1600UR Service Guide...

  • Page 170: System Access Warnings

    To avoid risk of potential electric shock, a proper safety ground must be implemented for the rack and each piece of equipment installed in it. ® Intel Server System SR1600UR Service Guide...

  • Page 171: Electrostatic Discharge (Esd)

    Caution: To avoid risk of radiation exposure and/or personal injury: • Do not open the enclosure of any laser peripheral or device • Laser peripherals or devices have are not user serviceable • Return to manufacturer for servicing ® Intel Server System SR1600UR Service Guide...

  • Page 172: Deutsch

    Deutsch Sicherheitshinweise für den Server ® ® Das vorliegende Dokument bezieht sich auf Intel Serverplatinen, Intel Servergehäuse (Standfuß und Rack) sowie installierte Peripheriegeräte. Es enthält Warnungen und Vorsichtsmaßnahmen zur Vermeidung von Gefahren durch Verletzung, Stromschlag, Feuer und Beschädigungen von Geräten. Lesen Sie diese Dokument daher sorgfältig, ®...

  • Page 173: Zielbenutzer Der Anwendung

    Verwenden Sie mechanische oder andere geeignete Hilfsmittel zum Transportieren oder Anheben von Geräten. • Entfernen Sie alle Komponenten, die sich leicht abnehmen lassen, um das Gewicht zu reduzieren und die Handhabung zu erleichtern. ® Intel Server System SR1600UR Service Guide...

  • Page 174: Warnungen Zu Netzspannung Und Elektrizität

    Typ entspricht. Jedes Netzteil im System muß über ein eigenes Netzkabel angeschlossen werden. Einige Netzteile von Intel Servern verwenden Nullleitersicherungen. Vorsicht ist geboten im Umgang mit Netzteilen, welche Nullleitersicherungen verwenden, um das Risiko eines elektrischen Schlages zu vermeiden Das Netzteil in diesem Produkt enthält keine Teile, die vom Benutzer gewartet werden...

  • Page 175: Warnhinweise Für Den Systemzugang

    Gehen Sie bei der Installation von Geräten im Rack immer von unten nach oben vor, und bauen Sie das schwerste Gerät an der untersten Position im Rack ein. Ziehen Sie jeweils immer nur ein Gerät aus dem Rack heraus. ® Intel Server System SR1600UR Service Guide...

  • Page 176: Elektrostatische Entladungen (Esd)

    Inbetriebnahme des Systems ohne Abdeckung kann zur Beschädigung von Systemkomponenten führen. So bringen Sie die Abdeckung wieder an: • Vergewissern Sie sich zunächst, daß Sie keine Werkzeuge oder Teile im Gehäuse vergessen haben. ® Intel Server System SR1600UR Service Guide...

  • Page 177: Français

    ® d’installer ou de mettre à jour votre produit serveur Intel En cas de conflit entre les informations fournies dans ce document et celles livrées avec le produit ou publiées sur le site Web pour un produit particulier, la documentation du produit prime.

  • Page 178: Domaines D'utilisation Prévus

    Bien ventilé et à l’écart des sources de chaleur telles que la lumière directe du soleil et les radiateurs. • À l’écart des sources de vibration ou des chocs physiques. • Isolé des champs électromagnétiques importants produits par des appareils électriques. ® Intel Server System SR1600UR Service Guide...

  • Page 179: Pratiques De Manipulation De L'équipement

    Vous devez les débrancher avant d’ouvrir le châssis, d’ajouter ou de supprimer un composant non connectable à chaud. Les alimentations de certains serveurs Intel sont munies de doubles fusibles pôle/neutre: veuillez observer les précautions d'usage afin d'éviter tout risque d'eléctrocution.

  • Page 180: Avertissements Sur Le Cordon D'alimentation

    Éteignez le système en appuyant sur le bouton d’alimentation. • Déconnectez l’alimentation secteur en débranchant tous les cordons d’alimentation secteur du système ou de la prise murale. • Déconnectez l’ensemble des câbles et lignes de télécommunication qui sont connectés au système. ® Intel Server System SR1600UR Service Guide...

  • Page 181: Avertissements Sur Le Montage En Rack

    étiqueté comme contrôlant toute l’unité, et pas uniquement le ou les serveurs. Pour éviter tout risque d’électrocution, le rack et chaque élément de l’équipement installé dans le rack doivent être correctement reliés à la terre. ® Intel Server System SR1600UR Service Guide...

  • Page 182: Décharges Électrostatiques (Esd)

    Vérifiez tout d’abord que vous n’avez pas oublié d’outils ou de composants détachés à l’intérieur du système. • Vérifiez que les câbles, les cartes d’extension et les autres composants sont correctement installés. • Fixez les panneaux au châssis en suivant les instructions du produit. ® Intel Server System SR1600UR Service Guide...

  • Page 183: Périphériques Laser

    Español Información de seguridad del servidor Este documento se aplica a las tarjetas de servidor de Intel®, las carcasas de servidor de Intel® (montaje en bastidor y en pedestal) y los dispositivos periféricos. Para reducir el riesgo de daños corporales, descargas eléctricas, fuego y en el equipo, lea este documento y preste atención a todos las advertencias y precauciones de esta guía antes de instalar o...

  • Page 184: Aplicaciones Y Usos Previstos

    Provista de una toma de corriente alterna correctamente conectada a tierra. • Provista de espacio suficiente para acceder a los cables de la fuente de alimentación ya que constituyen la desconexión principal de la alimentación. ® Intel Server System SR1600UR Service Guide...

  • Page 185: Manipulacién Del Equipo

    CA estén desenchufado antes de abrir la carcasa, agregar o extraer cualquier componente que no es de conexión en funcionamiento. Algunas fuentes de alimentación de electricidad de los servidores de Intel utilizan el polo neutral del fuselaje. Para evitar riesgos de choques electricos use precauciónes al trabajar con las fuentes de alimentación que utilizan el polo neutral de fuselaje.

  • Page 186: Advertencias El Acceso Al Sistema

    Devuélvala al fabricante para repararla. • Apague el servidor y desconecte todos los cables de alimentación antes de agregar o reemplazar cualquier componente que no es de conexión en funcionamiento. ® Intel Server System SR1600UR Service Guide...

  • Page 187: Advertencias Sobre El Montaje En Bastidor

    Precaución: Las descargas electrostáticas pueden dañar las unidades de disco, las tarjetas y otros componentes. Recomendamos que realice todos los procedimientos en una estación de trabajo protegida contra descargas electrostáticas. En caso de que no haya una ® Intel Server System SR1600UR Service Guide...

  • Page 188: Otros Riesgos

    Compruebe primero que no ha dejado herramientas o piezas sueltas dentro del sistema. • Compruebe que los cables, tarjetas adicionales y otros componentes están instalados correctamente. • Sujete las cubiertas a la carcasa siguiendo las instrucciones del producto. ® Intel Server System SR1600UR Service Guide...
  • Page 189 Precaución Para evitar el riesgo de la exposición a radiaciones o de daños personales: • No abra la caja de ningún periférico o dispositivo láser • Los periféricos o dispositivos láser no pueden ser reparados por el usuario • Haga que el fabricante los repare ® Intel Server System SR1600UR Service Guide...
  • Page 190 ® Intel Server System SR1600UR Service Guide...

Table of Contents
