Internal Components (SR1630GP)
A.
Rack Handles (two)
B.
Server Board
C.
Processor Air Duct
D.
PCIe* Riser Assembly
E.
Processor and Heatsink
F.
Power Supply
®
Intel
Server System SR1630GP / SR1630HGP Service Guide
Figure 6. System Components (SR1630GP)
G.
System Memory DIMM Sockets
H.
System Blower Fans (two)
I.
Hard Drive Bays
J.
Front Panel
K.
Slimline Optical Drive Bay
AF003242
