System Front Panel (SR1630HGP)

The front of the server system includes the following buttons and LEDs.
Table 3. Intel® Server System SR1630HGP Control Panel LED Functions
LED Color
NIC 1 / NIC 2 Green
Activity
Green
Power / Green
Sleep
Off
System N/A
Status (on
standby
power)
Disk Activity Green
Off
®
Intel Server System SR1630GP / SR1630HGP Service Guide
A. NIC1 LED
B. NIC2 LED
C. Power LED
D. System Status LED

Figure 4. Front Controls and LEDs (SR1630HGP)

State
On
Blink
On
Blink
Off
N/A
Random
blink
Off
B E
A
C D
G F
AF001573
E. HDD Activity LED
F. USB Port
G. Power Button
Description
NIC Link / System is On
LAN access
Power on
Sleep / ACPI S1 state
Power Off / ACPI S4 state
N/A
HDD access
No hard disk drive activity
7
