Intel
Server Board S5500BC,
®
Intel
Server Chassis SC5650,
®
Intel
Server System SR1630BC,
®
Spares / Parts List & Configuration Guide
A reference guide to assist customers in ordering the necessary components to configure the
Intel® Server board S5500BC, Intel® Server chassis SC5650 and Intel® server system
SR1630BC
Enterprise Platforms and Services Marketing
Revision 1.0
January, 2009
~ Subject to Change ~
Advertisement
Table of Contents
Related Manuals for Intel S5500BC
Summary of Contents for Intel S5500BC
- Page 1 ® Spares / Parts List & Configuration Guide A reference guide to assist customers in ordering the necessary components to configure the Intel® Server board S5500BC, Intel® Server chassis SC5650 and Intel® server system SR1630BC Enterprise Platforms and Services Marketing ~ Subject to Change ~ Revision 1.0...
-
Page 2: Change History
Current characterized errata are available on request. Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. -
Page 3: Table Of Contents
Production RAID Accessories (not including BBU) ... 16 Production RAID Controller... 16 Intel® System Management Software – (Upgrade SKUs)... 17 Intel® System Management Software – Upgrade Order Codes: ... 18 Production Intel Xeon Processor 5500 Series ... 20 Production Intel Thermal Solution STS100 Series ... 21... -
Page 4: Production Configurations
Resource CD-ROM with utilities, drivers, documentation and technical information ISMS 3.x DVD Compatible with Intel® Xeon® processor 5500 series 2. The production OEM 10-packs of Intel® Server Boards contain the following: Each baseboard with Common Enabling Kit (CEK) spring clips Compatible with Intel® Xeon® processor 5500 series Production chassis 1. -
Page 5: Production Integrated 1U System
The chassis is designed to work with boxed Intel® Xeon® processor 5500 series using Intel® Thermal Solution STS100C (Combo) or STS100A (Active). 2. The production Intel® Server Chassis SC5650BRP SKU includes: Redundant (1+0) 600W high efficiency PFC power supply with dual line cord support (full redundancy... - Page 6 Front Panel Cable (baseboard header to front panel) USB Cable (USB header to chassis front panel) Two SATA cables AC power cord is included in SR1630BCNA The system is designed to work with boxed Intel® Xeon® processor 5500 series using Intel® Thermal Solution STS100P (passive)
-
Page 7: Production Order Codes
Product Code AXXTIO MM # 900774 00735858208109 900775 00735858208116 MM # 901685 00735858207683 Description Boxed Intel Server Board S5500BC. (Includes I/O shield, cables, resource CD and ISMS DVD) Bulk pack of the Intel Server Board S5500BC Description 50 Pack: I/O Shield... -
Page 8: Production Chassis
Check the Power budget spreadsheet for supportable hard drive, memory and PCI configurations. Supports S5520HC, S5500HCV, S5500BC. Supports up to 95W processor. No power cord or heat sinks included. Same as Intel Server Chassis SC5650DP with North American power cord. No heat sinks included. -
Page 9: Production Chassis Spares And Accessories
6-drive hot-swap non-expanded SATA/SAS backplane 900405 00735858207638 assembly cage kit for Intel Server Chassis SC5600 / SC5650 family. Requires 6 SAS ports from RAID card for SAS (or SATA) 3.5” hard drive support or 6 SATA ports from baseboard or RAID card for SATA 3.5” hard drive support. - Page 10 6-bay Hot-swap Hard Disk Cage AXX6DRV3GR in SC5650 Chassis 882456 00735858177450 Hot-swap adapter bracket for use with all Intel Server Chassis SC5299-E, SC5295 (except SC5295UP) and SC5650 chassis. This mounting kit is required when using 6-bay Hot-swap Hard Disk Cage...
- Page 11 (for empty module when only 1 module installed). See Technical Product Specifications for instructions. 4 wire fan kit for Intel Server Chassis SC5650. Includes (1) 4 wire PCI Fan(120mm) & (2) 4 wire rear fan(120mm) & (1) 4 wire HDD fan(90mm).
- Page 12 DB9) one for DSD and one for DCD (modem). The kit also includes one serial ribbon cable for cabling 2nd serial port from the baseboard. Note this ribbon cable used with Intel Server SC5600/SC5650 Spare board for AXX6DRV3GR (6 drive backplane without an expander).
-
Page 13: Production System Sr1630Bc
Product Code SR1630BC SR1630BCNA 880265 00735858181938 Hot swap drive carrier spare with black baffle. 879287 00735858180740 Spare North America Power cable for Intel Server Chassis SC5600, SC5650 family MM # 900773 00735858208123 00735858208161 901893 Description Intel integrated 1U Server System SR1630BC (includes baseboard, 1 riser card, 2 non-redundant chassis fans, fixed HE 400W power supply, 2x3.5"... -
Page 14: Production System Sr1630Bc Accessory
Production System SR1630BC Accessory Picture Product Code Coming Soon AHJBEZBLACK Coming Soon AXXBASICRAIL Coming Soon AXXBRACKETS Coming Soon AXXHERAIL Coming Soon AXXSATADVDROM Coming Soon AXXSATADVDRWROM Coming Soon FPWRCABLENA Production System SR1630BC Spares Picture Product Code AHJTPCIERISER FHJT400WPS MM # 888348 00735858192163 881096 00735858184748... - Page 15 FHJTBLOWER Coming Soon FHJTFIXPMKIT 00735858208154 SR1630 blower spare kit. 900770 00735858208147 SR1630BC Fixed drive maintenance kit 900771 Kit includes front panel assembly, CD-ROM brackets, air duct, various cables, and screws...
-
Page 16: Production Raid Accessories (Not Including Bbu)
Intel® RAID Controller SRCSAS16PHI - PCIe x8, 16P SAS RAID Controller, 256MB 667MHz memory embedded. Note: Compatible in SC5650DP/BRP chassis Intel® RAID Controller SRCSASBB8I - PCIe x8, 8P SAS RAID Controller, 256MB embedded memory, MD2 Low Profile, half length form factor. Compatible in both S5650DP/BRP and SR1630BC. -
Page 17: Intel® System Management Software - (Upgrade Skus)
SASWT4I Intel® System Management Software – (Upgrade SKUs) The following Intel® System Management Software Upgrade SKUs are offered. Each SKU includes a Certificate of Authenticity (COA) that contains a product key for user to enter to upgrade: Upgrades available to Microsoft* System Center Essentials 2007 •... -
Page 18: Intel® System Management Software - Upgrade Order Codes
This upgrade gives the user the ability to manage 5 additional Windows-based client OSEs. • Upgrade to add 20 Client Management licenses This upgrade gives the user the ability to manage 20 additional Windows-based client OSEs. Intel® System Management Software – Upgrade Order Codes: Product Code SMS2SSE2SNE... - Page 19 SMS2CAL5C 7 35858 19673 4 893220 SMS2CAL20C 7 35858 19674 1 893219 Microsoft® System Center Essentials 2007 Server Management License (1 Pack) Not included: Software CDs are not included with upgrade. User must already have a valid copy of Microsoft* System Center Essentials 2007 to upgrade.
-
Page 20: Production Intel Xeon Processor 5500 Series
Production Intel Xeon Processor 5500 Series Boxed Processor Boxed Product Product Name Code Intel® Xeon® Processor X5570 BX80602X5570 901025 Intel® Xeon® Processor X5560 BX80602X5560 901026 Intel® Xeon® Processor X5550 BX80602X5550 901027 Intel® Xeon® Processor E5540 BX80602E5540 901028 Intel® Xeon® Processor E5530... -
Page 21: Production Intel Thermal Solution Sts100 Series
Production Intel Thermal Solution STS100 Series Product name Description Intel® Thermal Passive/Active Solution Combination Heat STS100C Sink with Removable Intel® Thermal Active Heat Sink Solution with Fixed Fan STS100A Intel® Thermal 25.5mm Tall Solution Passive STS100P Heat Sink MOQ = Minimum Order Quantity.
