Clearance Requirements

A minimum clearance of at least 6 inches (150 mm) is required above the product for
proper airflow. A minimum clearance of at least 24 inches (610 mm) is required on the
right side of the product for access to the electrical box. A minimum clearance of at least
36 inches (915 mm) is required on the front and rear side of the product to open the
Front and Rear Hatch, and to not restrict the exhaust airflow. Note: if opening the Rear
Hatch is not required, the rear clearance can be reduced to 24 inches (610 mm).
See Appendix B: Dimensions

Electrical Requirements

The product models have the following electrical requirements.
Typical Operating
Catalog Number
Current (Amps)
3300400, -10
3300401, -11
3300600, -10
3300601, -11
1 Electrical Requirements, 'V' = VAC (Voltage with alternating current), 'A' = Amperes
+ Wire must be rated at 80
A junction box supported by an appropriate and dedicated circuit breaker should be
located as close as possible to the product, but no greater than 10 feet (3 m) away. The
circuit breaker must be marked as the main disconnect device for this equipment. For
safe operation the dedicated circuit must provide a protective earthing ground
connection to the product. This product should be wired by a licensed electrician.
Do not connect a power cord to this product. It must be hard-wired as specified in this
manual

Service Line Requirements

All utility service lines should be ¼ inch O.D., brass, copper, or stainless steel, and
equipped with an easily accessible shut-off valve. The accessory service valves are
rated for operation at 40 PSI (275 kPa). If the service line pressure exceeds this, it must
be equipped with a pressure regulator to reduce the line pressure.
Note: The use of flammable gases or solvents should be avoided in the enclosure.
Open flame in the enclosure will disrupt the laminar airflow in the enclosure and may
damage the HEPA filters. If you feel that the procedure requires the use of an open
flame or flammable materials, contact your institution's safety office.
Note: The use of air or gases under high pressure should be avoided as they may
seriously disrupt the airflow patterns in the cabinet.
for overall product dimensions.
Electrical Circuit Requirements
6 A 115 V, 60 Hz, 30 A
3 A 230 V, 50/60 Hz, 20 A
8 A 115 V, 60 Hz, 30 A
4 A 230 V, 50/60 Hz, 20 A
o
C minimum
12
Service Wire
1
Gauge
1 Phase 10 AWG (6mm
1 Phase 12 AWG (4mm
1 Phase 10 AWG (6mm
1 Phase 12 AWG (4mm
2 +
)
2 +
)
2 +
)
2 +
)
