Step 2 – Pallet Removal
Move the enclosure, attached to its pallet, by using a floor jack, or forklift, to an open
area with room to remove the enclosure from its pallet. DO NOT tilt the enclosure.
See Figure 4-2, and remove the following items:
• Shrink wrap film around the entire product
• Sash Brackets (2) and Foam Pads (support when removing last bolt) – discard
• Scissor Jack (located in box on pallet)
• Levelling Feet (located in separate box on pallet)
• Pallet Ramp (attached to pallet with four (4) phillips screws) – save the screws!
SASH
BRACKETS
(2)
WHITE
PARTS
BOX
SCISSOR
JACK
BOX WITH
LEVELLING FEET (4)
Figure 4-2
PALLET RAMP
25
SHIPPING
BRACKETS (2)
