6. Slide the insert on the cable to the location where it will reside once installed in the
Pass Thru in the end wall. For example, if the cable will extend into the enclosure
3 feet from the Pass Thru, locate the insert 3 feet from the end that will reside
inside the enclosure.
7. Run the end of the cable through the opening in the outer End Panel, then through
the opening in the Entry Frame.
Note: The opening in the End Panel is through a plate with a smaller slot. This plate is
decorative, and can be left off if the cable end (for example a power cord plug) is too
large to fit through the smaller slot in the plate. If the plate is removed, replace the two
(2) screws that secured the plate into the End Panel.
8. Position the new insert into the Pass Thru Frame Bottom where the solid plug was
removed. Add any other cables and their required insert at this time.
9. Replace the Pass Thru Frame Top onto the inserts in the Pass Thru Frame
Bottom.
10. Snap the Pass Thru Frame with all inserts now in place back into the Entry Frame.
11. Lightly pull the cable(s) to make sure they do not slide in the insert(s).
