Remove the two (2) Lower End Panels (see Figure 4-3). Remove the two (2) Top
Frame Brackets by removing the four (4) Bolts on each Top Frame Bracket. Discard
the Top Frame Brackets, protective white Pads, and Bolts. Reinstall the two (2) Lower
End Panels.
HEIGHT
ADJUSTMENT
BOLTS & NUTS
(4 PER END)
WHITE
PROTECTIVE
PADS (2)
Figure 4-3
CASTER/LEVELLING
FEET FRAME
26
LOWER
END
PANEL
PHILLIPS
SCREWS (4)
BOLTS (4)
TOP
FRAME
BRACKET
